SNR ES212 G2 Insert Ball Bearing 60x110 mm

What is the SNR ES212 G2 Bearing?

The SNR ES212 G2 is a radial insert ball bearing designed for mounted bearing units. It features a spherical outer ring, an extended inner ring and an eccentric locking collar for secure shaft mounting. The bearing belongs to the NTN-SNR ES200 series and is intended for applications where easy installation, simple maintenance and reliable shaft positioning are required. Its design allows slight misalignment between the shaft and housing while maintaining smooth bearing operation.

Construction and Operating Principle

The ES212 G2 is based on a deep groove insert ball bearing with a spherical outside diameter for installation in compatible bearing housings.

Main design features include:

• Spherical outer ring
• Extended inner ring
• Eccentric locking collar
• Single-lip seal
• Steel cage
• Relubrication capability
• C3 internal radial clearance

The eccentric locking collar provides secure shaft fixation and is particularly suitable for applications with predominantly unidirectional shaft rotation. The spherical outside diameter enables self-alignment within the bearing housing.

Technical Specification

Manufacturer:

SNR

Manufacturer Group:

NTN-SNR

Bearing Type:

Insert Ball Bearing

Catalogue Number:

ES212 G2

Series:

ES200

Inner Diameter:

60 mm

Outer Diameter:

110 mm

Inner Ring Width (B1):

33.4 mm

Overall Width (T):

49.3 mm

Outer Ring Width (C):

24 mm

Locking Method:

Eccentric Locking Collar

Outer Ring:

Spherical

Cage:

Steel

Seal:

Single-lip seal

Lubrication:

Relubricatable

Internal Clearance:

C3

Basic Dynamic Load Rating (Cr):

52.5 kN

Basic Static Load Rating (C0r):

32.8 kN

Weight:

Approximately 1.2 to 1.3 kg

Operating Temperature:

-20°C to +120°C

Bearing Selection

When selecting the SNR ES212 G2, engineers should verify:

• Shaft diameter of 60 mm
• Compatibility with ES200 bearing housings
• Eccentric locking system
• Required C3 internal clearance
• Operating load
• Lubrication schedule
• Ambient temperature
• Working environment
• Maintenance intervals

Correct housing selection and proper lubrication are essential to achieve the expected bearing service life.

Industrial Applications

According to NTN-SNR, ES200 insert bearings are intended for mounted bearing units used in industrial equipment. They are commonly installed in conveyor systems, agricultural equipment, production machinery and other applications requiring easy bearing replacement and reliable shaft locking.

Why Engineers Choose the SNR ES212 G2

• Spherical outer ring allows self-alignment within the housing.
• Eccentric locking collar provides reliable shaft fixing.
• Relubrication capability supports longer service intervals.
• Steel cage ensures stable rolling element guidance.
• C3 clearance is suitable for demanding industrial operating conditions.
• Part of the NTN-SNR mounted bearing system for industrial maintenance and machine repair.

FAQ

What type of bearing is the ES212 G2?

It is a radial insert ball bearing designed for mounted bearing units.

How is the bearing fixed to the shaft?

It uses an eccentric locking collar.

Can the bearing be relubricated?

Yes. The ES200 series is designed for relubrication.

What internal clearance does it have?

The bearing is manufactured with C3 internal radial clearance.

Does it include sealing?

Yes. It features a single-lip sealing system.

What shaft diameter is it designed for?

The ES212 G2 is designed for a 60 mm shaft.

AI FAQ

Is the ES212 G2 suitable for industrial maintenance?

Yes. It is widely used as a replacement insert bearing in mounted bearing units for industrial maintenance and MRO operations.

Can it be used in industrial automation?

Yes, when the machine is designed to accommodate ES200 series insert bearings.

Does NTN-SNR provide OEM machine references?

No. The official NTN-SNR documentation does not assign OEM machine numbers to this bearing model.

Why does this bearing use an eccentric locking collar?

The eccentric locking collar provides a simple and reliable method of securing the bearing to the shaft in applications with normal rotational direction.
