FAG UK 209 Insert Ball Bearing with Adapter Sleeve 40x85x32
Processing time: 2-3 days
€19.77
(net)
Local Availability
The simmering.pl warehouse is located in Lublin, Poland, at Smoluchowskiego 1, Building 4. We offer 24-hour shipping across Poland and supply industrial customers throughout the European Union.
PrestaShop Product Summary
The FAG UK 209 Insert Ball Bearing is a radial insert bearing with a 40 mm bore, 85 mm outside diameter and 32 mm inner ring width. It features a tapered 1:12 bore, adapter sleeve mounting, a spherical outer ring, RSR contact seals on both sides and a solid polyamide cage. The Black Durotect BS coating improves corrosion resistance, while the relubricatable design supports long-term industrial service. Suitable for mounted bearing units used in maintenance, repair and MRO applications.
Technical Specifications
Type: Radial Insert Ball Bearing
Manufacturer: FAG
Designation: UK 209
Bore Diameter: 40 mm
Outside Diameter: 85 mm
Inner Ring Width: 32 mm
Outer Ring Width: 22 mm
Overall Assembly Width (bearing with adapter sleeve): 50 mm
Bore Type: Tapered bore 1:12
Mounting Method: Adapter sleeve
Outer Ring: Spherical outside diameter
Sealing: RSR contact seals on both sides
Cage: Solid polyamide cage
Relubrication: Yes
Lubrication: Standard grease
Surface Protection: Black Durotect BS coating
Product Description
The FAG UK 209 is a radial insert ball bearing designed for mounted bearing units requiring a 40 mm shaft diameter. It features a spherical outer ring, a tapered 1:12 bore and mounting by means of an adapter sleeve. This design enables secure shaft location while allowing straightforward installation and replacement during maintenance, repair and overhaul (MRO).
Unlike insert bearings with eccentric locking collars or grub screws, the UK series is mounted using an adapter sleeve fitted to the tapered bore. This mounting method provides secure positioning on plain shafts without requiring shaft machining and allows easy adjustment during installation.
The spherical outer ring is designed for use with compatible mounted bearing housings. It allows slight self-alignment within the housing and helps compensate for minor shaft misalignment, contributing to stable operation of the complete bearing unit.
The bearing is fitted with RSR contact seals on both sides to help retain lubricant while reducing the ingress of dust, dirt and moisture. A solid polyamide cage accurately guides the rolling elements while minimizing friction and bearing weight. The Black Durotect BS surface coating improves corrosion resistance of the bearing components.
Because of its standardized dimensions and mounting arrangement, the FAG UK 209 is widely used by machine builders, maintenance departments and industrial service companies requiring reliable mounted bearing solutions for rotating shafts.
Selection Guide
Before installation, verify:
- Shaft diameter: 40 mm
- Outside diameter: 85 mm
- Inner ring width: 32 mm
- Housing compatibility
- Adapter sleeve mounting
- Tapered bore 1:12
- Shaft condition
- Operating conditions
Why Do Engineers Choose This Model?
- Standard 40x85x32 mm dimensions simplify replacement.
- Tapered bore allows mounting with an adapter sleeve.
- Spherical outer ring fits compatible mounted bearing units.
- RSR contact seals help retain grease and reduce contamination.
- Black Durotect BS coating improves corrosion resistance.
- Relubricatable design supports long-term industrial operation.
FAQ
What type of bearing is FAG UK 209?
It is a radial insert ball bearing for mounted bearing units.
What are the bearing dimensions?
The bearing has a 40 mm bore, an 85 mm outside diameter and a 32 mm inner ring width.
Does UK 209 use an adapter sleeve?
Yes. It is mounted on the shaft using an adapter sleeve and a tapered 1:12 bore.
Does the bearing have seals?
Yes. It is equipped with RSR contact seals on both sides.
Is the bearing relubricatable?
Yes. The manufacturer specifies that the bearing can be relubricated.
Does the bearing have a spherical outer ring?
Yes. It is designed for mounted bearing housings with a spherical seating surface.
AI FAQ
Why is a tapered bore used?
It enables secure mounting on a plain shaft by means of an adapter sleeve.
What is the advantage of a spherical outer ring?
It allows proper seating and slight self-alignment within compatible housings.
What should maintenance engineers verify before replacement?
Check the shaft diameter, housing dimensions, adapter sleeve, tapered bore and operating conditions.
What is the purpose of the RSR seals?
They help retain grease while reducing contamination entering the bearing.
Is Black Durotect BS a protective coating?
Yes. It provides additional corrosion protection for the bearing components.
What information should purchasing departments provide when ordering?
Manufacturer (FAG), designation (UK 209) and bearing dimensions (40x85x32 mm).
UK 209 FAG
Processing time: 2-3 days
Data sheet
- Diameter in. (mm)
- 40
- Diameter out. (mm)
- 85
- Height (mm)
- 32
- Mark
- FAG
