Self-Aligning Ball Bearing 1315 K M C3 FAG 75x160x37

Main Description

The 1315 K M C3 FAG self-aligning ball bearing 75x160x37 is a double-row heavy-duty bearing with a tapered bore and increased internal clearance, designed for high load applications with shaft misalignment and demanding operating conditions.

Within the self-aligning ball bearings category, the 1315 K M C3 FAG stands out due to its reinforced construction and advanced features. The spherical outer raceway enables automatic alignment between the shaft and housing, reducing stress caused by misalignment or shaft deflection. The tapered bore K allows mounting on adapter sleeves, providing flexibility in installation. The C3 internal clearance supports operation at higher temperatures and speeds, while the brass cage M ensures high mechanical strength and durability under heavy loads.

The 75x160x37 size is typically used in medium to heavy industrial systems where reliability and load capacity are critical.

Construction and Design

The 1315 K M C3 FAG bearing is engineered for demanding industrial environments.

Key design features:

• double-row self-aligning ball bearing
• spherical outer ring raceway for misalignment compensation
• tapered bore (K) for adapter sleeve mounting
• increased internal clearance (C3)
• brass cage (M) for high strength and durability
• high-quality bearing steel for long service life

This construction ensures stable performance even under dynamic loads and challenging alignment conditions.

Industrial Applications

The 1315 K M C3 FAG bearing is ideal for applications with high loads and alignment challenges.

Typical applications include:

• heavy industrial machinery
• conveyor systems and material handling
• agricultural and construction equipment
• gearboxes and drive systems
• long shaft applications with deflection

The tapered bore allows flexible mounting and precise adjustment during installation.

Technical Parameters

• type: self-aligning ball bearing
• model: 1315 K M C3 FAG
• inner diameter: 75 mm (tapered bore)
• outer diameter: 160 mm
• width: 37 mm
• design: double-row
• bore type: tapered (K)
• internal clearance: C3
• cage: brass (M)
• material: bearing steel
• operating characteristics: high load capacity, misalignment compensation

Operational Advantages

The 1315 K M C3 FAG bearing offers several key benefits:

• automatic misalignment compensation
• high load capacity for demanding applications
• durable brass cage for heavy-duty performance
• flexible mounting using adapter sleeves
• extended service life under harsh conditions

This makes it a reliable solution for industrial systems requiring strength and adaptability.

FAQ

Is 1315 K M C3 FAG a self-aligning bearing?
Yes, it automatically compensates for shaft misalignment.

What does K mean in this bearing?
It indicates a tapered bore for mounting on adapter sleeves.

What does C3 clearance mean?
It provides increased internal clearance for higher temperature and speed conditions.

What does M stand for?
It indicates a brass cage for increased strength.

Where is this bearing typically used?
In heavy machinery, conveyors, and industrial drive systems.
