1309 K CMB self aligning ball bearing 45x100x25

Industrial applications

The 1309 K CMB self aligning ball bearing is designed for applications where shaft misalignment or deflection occurs during operation. It is widely used in conveyors, fans, agricultural machinery, and industrial drive systems.

Thanks to its 45x100x25 mm dimensions, this bearing is suitable for medium-duty mechanical systems requiring flexibility and reliability under varying operating conditions.

Construction and design

1309 K CMB is a double row self aligning ball bearing featuring a spherical outer raceway, allowing automatic alignment between the shaft and housing. This design compensates for angular misalignment and reduces stress on the bearing.

The tapered bore (K) enables mounting on adapter sleeves or tapered shafts, providing flexibility in installation. The CMB version indicates a matched bearing set, ensuring precise fit and stable operation.

Technical parameters

Type: self aligning ball bearing double row
Model: 1309 K CMB
Inner diameter: 45 mm
Outer diameter: 100 mm
Width: 25 mm
Bore type: tapered (K)
Design: self aligning
Load type: radial and moderate axial
Application: industrial, machinery, drive systems

Operational advantages

This bearing offers excellent misalignment compensation, significantly increasing system durability and reducing the risk of premature failure.

The double row design enhances load capacity and stability, while the tapered bore allows precise mounting and adjustment. These features make it ideal for applications with installation inaccuracies or shaft deflection.

Main description

1309 K CMB is a self aligning ball bearing designed to operate in systems where shaft misalignment, deflection, or mounting inaccuracies are present, ensuring reliable performance and extended service life.

Within the category of self aligning ball bearings, the 1309 model belongs to a widely used series for industrial and mechanical applications. The 45x100x25 mm configuration is commonly used in conveyors, rotating machinery, and drive systems.

Self aligning ball bearings are known for their ability to compensate for misalignment and maintain stable operation under dynamic conditions. The tapered bore version allows flexible mounting, improving installation accuracy and performance.

In industrial practice, this bearing is used in systems where alignment cannot be perfectly maintained. As part of the self aligning bearing cluster, it provides a versatile and reliable solution for demanding applications.

FAQ

What is a self aligning ball bearing used for?
It is used to compensate for shaft misalignment.

What does K mean in this bearing?
It indicates a tapered bore for sleeve mounting.

What does CMB mean?
It refers to a matched bearing set.

Where is 1309 K commonly used?
In conveyors, fans, and industrial machinery.

Can it handle axial loads?
Yes, moderate axial loads in addition to radial loads.
