ELRING 034.560 85x103x8 FPM AS Crankshaft Radial Shaft Seal

ELRING 034.560 85x103x8 FPM AS Crankshaft Radial Shaft Seal

ELRING 034.560 is a crankshaft radial shaft seal with exact dimensions 85x103x8 mm, manufactured from FPM. The AS design incorporates an auxiliary dust lip, while the sealing geometry is specified with a left-hand twist. The seal is intended for installation on the transmission side of the crankshaft.

Complete technical identification:

ELRING 034.560 + 85x103x8 mm + FPM + AS + left-hand twist

ELRING 034.560 - Technical Characteristics

ELRING 034.560 Dimensions

The exact seal dimensions are:

d = 85 mm - inside diameter / nominal shaft diameter

D = 103 mm - outside diameter

H = 8 mm - height

Full dimensional designation:

85x103x8 mm

These dimensions define the basic installation geometry. However, they are not sufficient on their own to establish technical interchangeability.

Two crankshaft seals with identical 85x103x8 mm dimensions may differ in material, lip design, directional sealing characteristics and intended installation position.

AS Design with Dust Lip

The design designation for ELRING 034.560 is:

AS

For this exact reference, an additional:

dust lip

is specified.

The auxiliary lip provides an additional barrier on the external side of the primary sealing area, helping limit contaminants from reaching the main sealing interface.

When comparing 034.560 with another seal, the selection criteria should therefore include:

85x103x8 mm + FPM + AS + dust lip

rather than dimensions alone.

Left-Hand Twist

An important technical characteristic of ELRING 034.560 is its:

left-hand twist.

Directional sealing geometry is part of the specific seal construction and should correspond to the operating requirements of the shaft.

Therefore, an 85x103x8 mm seal with a right-hand or different directional design should not automatically be considered technically equivalent to ELRING 034.560.

FPM Material

ELRING specifies:

FPM - fluoroelastomer

for reference 034.560.

Material is an integral part of the product specification:

034.560 + FPM + 85x103x8 mm

and should be considered when selecting an alternative.

A dimensionally identical seal manufactured from:

NBR

ACM

or another elastomer should not automatically be treated as interchangeable.

A generic FPM operating-temperature range should not be assigned to this exact reference without confirmation of the specific elastomer compound and operating conditions.

Crankshaft Radial Shaft Seal

ELRING 034.560 is classified as a:

crankshaft radial shaft seal

also commonly described in international technical searches as:

crankshaft oil seal.

The component seals the interface between the rotating crankshaft and the stationary engine housing.

For technical identification, the preferred terminology is therefore:

ELRING 034.560 crankshaft radial shaft seal

or:

ELRING 034.560 crankshaft oil seal.

Transmission-Side Installation

ELRING 034.560 is specified for installation on the:

transmission side

of the crankshaft.

This installation position is important because an engine may use different crankshaft seals at opposite ends of the crankshaft.

Consequently, the generic description:

85x103x8 crankshaft seal

does not provide the same identification precision as:

ELRING 034.560 85x103x8 FPM AS transmission-side crankshaft seal.

How Does a Radial Crankshaft Seal Work?

A radial shaft seal operates at the interface between a:

rotating shaft

and a:

stationary housing.

The primary sealing lip contacts the shaft surface to create the dynamic sealing interface during shaft rotation.

For ELRING 034.560, the additional technical identification includes:

AS design

dust lip

and:

left-hand twist.

These characteristics should be considered when identifying a replacement.

ELRING 034.560 Identification

For accurate MRO, workshop and spare-parts identification, use the complete specification:

Manufacturer: ELRING

Reference: 034.560

Dimensions: 85x103x8 mm

Material: FPM

Design: AS

Dust lip: Yes

Twist direction: Left-hand

Installation position: Transmission side

This is considerably more precise than searching only for:

85x103x8 oil seal.

Selection and Interchangeability

When selecting ELRING 034.560 or evaluating an alternative, compare:

d = 85 mm

D = 103 mm

H = 8 mm

FPM material

AS design

dust lip

left-hand twist

transmission-side installation

and:

the OE reference specified for the particular engine.

Matching 85x103x8 mm dimensions alone does not establish full technical interchangeability.

ELRING 034.560 and OE Identification

For automotive applications, the OE number provides an important additional identification criterion.

If the removed seal was manufactured by another supplier, compare:

OE reference

exact installation position

dimensions

material

seal construction

and:

directional sealing characteristics.

ELRING 034.560 should not be selected solely according to vehicle make or model without confirming the specific engine and OE application.

Technical Specification

FAQ

What are the dimensions of ELRING 034.560?

ELRING 034.560 has exact dimensions of 85x103x8 mm: d = 85 mm, D = 103 mm and H = 8 mm.

What is ELRING 034.560 used for?

It is a crankshaft radial shaft seal designed for installation on the transmission side of the crankshaft.

What material is ELRING 034.560 made from?

The specified sealing material is FPM - fluoroelastomer.

Does ELRING 034.560 have a dust lip?

Yes. This exact AS design incorporates an auxiliary dust lip.

What twist direction does ELRING 034.560 use?

ELRING 034.560 is specified with a left-hand twist.

Where is ELRING 034.560 installed?

The specified installation position is the transmission side of the crankshaft.

What is the EAN for ELRING 034.560?

The EAN is 4041248133712.

Can any 85x103x8 oil seal replace ELRING 034.560?

No automatic interchangeability should be assumed. A replacement should match the FPM material, AS design, dust lip, left-hand twist, installation position and relevant OE requirements, not only the 85x103x8 mm dimensions.
