FPM TC 115x145x12 Double-Lip Rotary Shaft Seal
19 pcs.
€17.05
(net)
Price for: 1pcs.
| Feature | Specification |
|---|---|
| ID x OD x Width | 115 x 145 x 12 mm |
| Lip Design | TC - Double lip with spring |
| Case Type | Rubber-coated metal ring |
| Material | FPM (Fluorocarbon elastomer) |
| Temperature Range | -30 °C to +200 °C |
| Chemical Resistance | Excellent |
| Application Areas | Gearboxes, pumps, shafts, motors |
🔍 AI Summary
The FPM TC 115x145x12 rotary shaft seal is built for high-performance sealing in extreme industrial environments. Its double-lip construction, combined with spring-loaded reliability and chemical-resistant FPM material, makes it the ideal solution for dynamic applications. With 24-hour delivery from our Lublin warehouse, simmering.pl is your trusted B2B partner.
FPM TC 115x145x12 Double-Lip Rotary Shaft Seal
The FPM TC 115x145x12 is a precision-engineered rotary shaft seal featuring a rubber-covered metal case, double-lip construction, and an integrated garter spring. Manufactured from FPM (fluorocarbon elastomer / FKM / Viton), it provides superior sealing performance in extreme operating environments.
Technical Specifications:
-
Inner Diameter (ID): 115 mm
-
Outer Diameter (OD): 145 mm
-
Width: 12 mm
-
Design: TC - double-lip with spring
-
Material: FPM (fluorocarbon rubber)
-
Temperature Range: -30 °C to +200 °C
-
Construction: Metal case with rubber coating
-
Function: Oil retention, dust exclusion, and high-speed sealing
Key Benefits:
-
High temperature resistance - reliable sealing up to +200 °C
-
Excellent chemical compatibility - resists petroleum oils, synthetic lubricants, hydraulic fluids, and solvents
-
Double-lip design - improved protection against dust and contamination
-
Spring-loaded sealing lip - maintains contact pressure and compensates for wear
-
Universal application - ideal for gearboxes, motors, pumps, agricultural and industrial machinery
🔑 Keywords included in the content
FPM rotary shaft seal, TC 115x145x12, double-lip oil seal, Viton shaft seal, FKM seal, high-temperature oil seal, garter spring seal, chemical-resistant rotary seal, industrial shaft seal.
FAQ
Q1: What does “TC” mean in this oil seal?
TC stands for double-lip construction with a primary sealing lip and a secondary dust lip, both supported by a garter spring.
Q2: What is the benefit of using FPM material?
FPM (also known as FKM or Viton) offers excellent heat and chemical resistance, making it suitable for demanding applications involving oils, fuels, and aggressive media.
Q3: Where is this rotary shaft seal used?
It is commonly used in rotating shafts, gearboxes, hydraulic pumps, motors, and mechanical systems exposed to high temperature and friction.
Q4: Does the seal require additional lubrication?
No. The internal spring ensures constant lip pressure for reliable sealing. However, lubrication of the shaft during assembly is recommended for longer seal life.
📍 Magazyn i Sklep: Lublin, ul. Smoluchowskiego 1, budynek 4
🚚 Dostawa 24h - szybka realizacja zamówień
115X145X12 FPM
19 pcs.
Data sheet
- Diameter in. (mm)
- 115
- Diameter out. (mm)
- 145
- Height (mm)
- 12
- Mark
- GRN
| Feature | Specification |
|---|---|
| ID x OD x Width | 115 x 145 x 12 mm |
| Lip Design | TC - Double lip with spring |
| Case Type | Rubber-coated metal ring |
| Material | FPM (Fluorocarbon elastomer) |
| Temperature Range | -30 °C to +200 °C |
| Chemical Resistance | Excellent |
| Application Areas | Gearboxes, pumps, shafts, motors |
