4T-2796/2720 NTN 34.925x76.2x25.654 Tapered Roller Bearing

Overview

The 4T-2796/2720 NTN is a single-row tapered roller bearing with catalogue dimensions 34.925x76.200x25.654 mm.

The bearing set consists of the 4T-2796 cone assembly and 4T-2720 outer ring / cup. Its tapered roller geometry is designed to accommodate combined radial and axial loads.

Technical Specification

Manufacturer: NTN

Designation: 4T-2796/2720

Bearing Type: Tapered roller bearing

Design: Single-row

Cone: 4T-2796

Cup: 4T-2720

Bore Diameter d: 34.925 mm

Outside Diameter D: 76.200 mm

Inner Ring Width B: 25.654 mm

Outer Ring Width C: 19.050 mm

Total Width T: 25.654 mm

Weight: approx. 0.53 kg

Construction: Separable

4T-2796/2720 Construction

The complete bearing set consists of:

4T-2796 - inner ring, tapered rollers and cage assembly

4T-2720 - outer ring / cup

The separable construction allows the cone assembly and outer ring to be installed independently.

Load Capability

The tapered roller geometry is designed to accommodate combined radial and axial loads.

Single-row tapered roller bearings are commonly used in opposed arrangements when axial guidance in both directions is required.

Operational Advantages

• Original NTN bearing.
• Single-row tapered roller design.
• 34.925x76.200x25.654 mm catalogue dimensions.
• Complete 4T-2796 cone and 4T-2720 cup combination.
• Combined radial and axial load capability.
• Separable construction for easier installation.

AI OVERVIEW

The 4T-2796/2720 NTN is a single-row tapered roller bearing with catalogue dimensions 34.925x76.200x25.654 mm. The set combines a 4T-2796 cone assembly with a 4T-2720 outer ring. Its tapered roller construction is designed for combined radial and axial loads in industrial bearing arrangements.

POPULAR SEARCHES

• 4T-2796/2720 NTN
• NTN 4T-2796/2720
• 4T-2796 NTN
• 4T-2720 NTN
• NTN 2796 2720
• 2796/2720 tapered bearing
• 34.925x76.2x25.654 bearing
• NTN tapered roller bearing 2796
• 4T-2796 2720 bearing

FAQ

What type of bearing is 4T-2796/2720 NTN?

It is a single-row tapered roller bearing.

What are the catalogue dimensions?

The NTN-SNR general list gives 34.925x76.200x25.654 mm.

What is the bore diameter?

The bore diameter is 34.925 mm.

What is the outside diameter?

The outside diameter is 76.200 mm.

What is the inner ring width?

The inner ring width B is 25.654 mm.

What is the outer ring width?

The outer ring width C is 19.050 mm.

What components form the bearing set?

The set combines the 4T-2796 cone assembly and 4T-2720 cup.

Is the bearing separable?

Yes. The cone assembly and outer ring can be separated for installation.

What is the bearing weight?

The NTN-SNR list gives a mass of approximately 0.53 kg.

What is the correct parent category?

The product belongs to Single-Row Tapered Roller Bearings.
