FAG 29330-E1 Spherical Thrust Roller Bearing - 150x250x60 mm | X-life Series

FAG 29330-E1 Spherical Thrust Roller Bearing - 150x250x60 mm | X-life Series

The FAG 29330-E1 is a premium spherical thrust roller bearing from the renowned X-life series, engineered to handle heavy axial loads in one direction. Its design ensures optimal performance in demanding industrial applications, offering extended service life and reduced maintenance needs.​

Technical Specifications

• Bore Diameter (d): 150 mm

• Outer Diameter (D): 250 mm

• Width (T): 60 mm

• Dynamic Load Capacity (Cr): 1,020,000 N

• Static Load Capacity (C0r): 2,900,000 N

• Weight: Approximately 10.5 kg

• Cage Material: Sheet steel or solid brass (depending on size)

• Operating Temperature Range: -30°C to +200°C (limited by lubricant)​

Key Features

• X-life Quality: Enhanced performance with higher load ratings and extended service life.

• High Axial Load Capacity: Designed to support substantial axial forces in a single direction.

• Misalignment Compensation: Accommodates angular misalignments due to its spherical roller design.

• Optimized Lubrication: Improved surface quality ensures better lubricant film formation, reducing friction and wear.

• Versatile Applications: Suitable for use in gearboxes, marine propulsion systems, heavy machinery, and more.​

❓ Frequently Asked Questions (FAQ)

Q1: What does the 'E1' designation signify in FAG bearings?
A: The 'E1' indicates an optimized internal design, offering higher load capacities and improved performance compared to previous versions.​

Q2: Can this bearing accommodate radial loads?
A: While primarily designed for axial loads, the spherical thrust roller bearing can accommodate limited radial loads due to its design.​

Q3: Is the FAG 29330-E1 suitable for high-speed applications?
A: Yes, its design allows for relatively high-speed operations, but it's essential to ensure proper lubrication and operating conditions.​

Q4: What maintenance is required for this bearing?
A: Regular inspection and appropriate lubrication are recommended to ensure optimal performance and longevity.
