SKF 22226 EK 130x230x64 mm Spherical Roller Bearing

AI Overview

The SKF 22226 EK is a double-row spherical roller bearing with dimensions of 130x230x64 mm. It is designed to support high radial loads and axial loads acting in both directions while accommodating shaft misalignment. The bearing features a tapered bore (designation K) and is intended for demanding industrial applications where high load capacity and reliable operation are required.

Technical Data

Type: Spherical Roller Bearing

Manufacturer: SKF

Designation: 22226 EK

Series: 22200

Inside Diameter: 130 mm

Outside Diameter: 230 mm

Width: 64 mm

Rows: Double row

Bore: Tapered (K)

Product Description

The SKF 22226 EK is a double-row spherical roller bearing engineered for applications subjected to heavy radial loads and axial loads in both directions. Its self-aligning internal geometry enables the bearing to compensate for shaft deflection and housing misalignment, reducing stress on adjacent machine components.

With dimensions of 130 mm bore, 230 mm outside diameter and 64 mm width, this bearing is suitable for heavy-duty industrial equipment requiring high load capacity and dependable performance. The K designation indicates a tapered bore with a 1:12 taper, allowing mounting on tapered shafts or adapter sleeves according to SKF recommendations.

The spherical roller design provides excellent load distribution between the rollers and raceways while maintaining smooth operation under demanding operating conditions. These bearings are widely used in industrial machinery, mining equipment, conveyors, crushers, gearboxes, paper mills, steel processing equipment and other heavy-duty mechanical systems where reliability is essential.

Final bearing selection should always be based on the machine manufacturer's technical documentation and application requirements.

Bearing Selection

Before installation verify:

• Shaft diameter: 130 mm
• Housing bore: 230 mm
• Bearing width: 64 mm
• Tapered bore (K)
• Shaft and housing tolerances
• Applied loads
• Lubrication method
• Operating conditions
• Mounting method using the appropriate adapter or tapered shaft

Applications

Suitable for industrial machinery requiring the SKF 22226 EK spherical roller bearing in accordance with the equipment manufacturer's technical documentation.

Why do engineers choose this model?

• Double-row spherical roller design.
• High radial load capacity.
• Supports axial loads in both directions.
• Self-aligning construction compensates for shaft misalignment.
• Tapered bore (K) for flexible mounting.
• Standardized SKF dimensions.
• Suitable for OEM, industrial maintenance and MRO applications.

FAQ

What are the dimensions of the SKF 22226 EK bearing?
130 mm bore, 230 mm outside diameter and 64 mm width.

What does the K designation mean?
It indicates a tapered bore designed for mounting on tapered shafts or adapter sleeves.

How many rows of rollers does this bearing have?
Two rows.

Can this bearing compensate for shaft misalignment?
Yes. Its spherical roller design allows self-alignment.

What loads can it support?
High radial loads and axial loads acting in both directions.

Where is this bearing commonly used?
In heavy industrial machinery, conveyors, mining equipment, gearboxes, steel processing equipment and other demanding mechanical applications.
