20207-TVP-C3 FAG 35x72x17 mm - Spherical Roller Bearing

20207-TVP-C3 FAG 35x72x17 mm - Spherical Roller Bearing

FAG 20207-TVP-C3 is a single-row spherical roller bearing with dimensions 35x72x17 mm, a cylindrical bore, TVP polyamide cage and increased C3 internal clearance. Its self-aligning spherical roller design allows the bearing to accommodate angular misalignment between the shaft and housing. The bearing is primarily designed to support radial loads in applications where shaft deflection or mounting misalignment may occur.

Technical data - FAG 20207-TVP-C3

What does 20207-TVP-C3 mean?

The designation 20207-TVP-C3 identifies the specific FAG bearing version.

20207 - single-row spherical roller bearing with dimensions 35x72x17 mm.

TVP - solid cage made from polyamide.

C3 - radial internal clearance greater than Normal.

The absence of the K suffix is important. FAG 20207-TVP-C3 has a cylindrical bore.

The version 20207-K-TVP-C3 is a different design with a tapered bore.

FAG 20207-TVP-C3 dimensions

The principal dimensions are:

d = 35 mm - bore diameter

D = 72 mm - outside diameter

B = 17 mm - bearing width

Complete dimensions:

35x72x17 mm

When selecting an equivalent bearing, the dimensions alone are not sufficient. The bearing design, bore type, internal clearance and cage design must also be considered.

Single-row spherical roller bearing

20207-TVP-C3 belongs to the family of single-row spherical roller bearings.

The geometry of the roller and raceway system allows the bearing to accommodate angular misalignment between the inner and outer rings. This is one of the key differences between a spherical roller bearing and a conventional deep groove ball bearing.

This bearing design is particularly relevant in systems where there may be:

• shaft deflection

• housing misalignment

• mounting inaccuracies

• predominantly radial loads

• changing operating conditions

The permissible degree of misalignment depends on the actual bearing arrangement and operating conditions.

TVP polyamide cage

The suffix TVP identifies a solid cage made from polyamide.

The cage separates and guides the rolling elements, maintaining their correct position during bearing operation.

For applications involving unusual temperatures, lubricants or operating environments, the limitations associated with the cage material should also be considered.

C3 internal clearance

The suffix C3 indicates an internal clearance greater than Normal.

Increased internal clearance may be required where operating conditions reduce the initial bearing clearance due to factors such as:

• interference fits

• temperature differences

• thermal expansion

• specific operating conditions

C3 does not automatically mean that the bearing is suitable for every high-speed or high-temperature application.

The required internal clearance should always be selected according to the specific bearing arrangement.

Cylindrical bore - important difference from 20207-K-TVP-C3

FAG 20207-TVP-C3 has a cylindrical bore.

It should not be confused with:

FAG 20207-K-TVP-C3

The suffix K identifies a version with a tapered bore.

Both versions have principal dimensions of 35x72x17 mm, but their bore geometry and mounting requirements differ.

Therefore, 20207-TVP-C3 and 20207-K-TVP-C3 should not be considered identical products solely because their external dimensions are the same.

Load ratings of FAG 20207-TVP-C3

For this bearing size, the catalogue load ratings are approximately:

Cr = 41 kN - basic dynamic radial load rating

C0r = 43 kN - basic static radial load rating

Catalogue load ratings should not be interpreted as the permissible operating load of a specific bearing arrangement.

Actual bearing life depends on factors including load, rotational speed, lubrication, temperature, fits, lubricant cleanliness, alignment and installation conditions.

Misalignment capability

A characteristic feature of spherical roller bearings is their ability to accommodate misalignment between the shaft and housing.

This can be important in systems subject to:

• shaft deflection

• housing deformation

• minor mounting inaccuracies

• difficulties in maintaining precise alignment

This does not mean that the bearing can operate with unlimited angular misalignment. Permissible misalignment must be evaluated for the specific bearing arrangement and operating conditions.

Typical applications of 20207 spherical roller bearings

Single-row spherical roller bearings of this design can be used in various industrial machines and mechanical systems, particularly where radial load capacity and the ability to accommodate misalignment are required.

Typical application areas for this bearing type may include:

• industrial machinery

• conveying equipment

• gearboxes and drive systems

• agricultural machinery

• processing equipment

• shafts subject to deflection

• bearing arrangements where minor misalignment may occur

These are typical applications of this bearing design and do not confirm the suitability of FAG 20207-TVP-C3 for a specific machine.

Alternative designations and search references

This bearing may also be searched for as:

20207 TVP C3 FAG

20207-TVP-C3 FAG

FAG 20207 TVP C3

FAG 20207-TVP-C3

20207 C3 FAG

20207 TVP FAG

20207 35x72x17 FAG

FAG 20207 35x72x17

20207-TVP-C3 35x72x17

20207 spherical roller bearing

FAG 20207 spherical roller bearing

35x72x17 spherical roller bearing

The primary product identification is:

20207-TVP-C3 FAG 35x72x17 mm

Selection and interchangeability

When selecting a replacement for FAG 20207-TVP-C3, verify:

• bearing type - single-row spherical roller bearing

• bore diameter 35 mm

• outside diameter 72 mm

• width 17 mm

• cylindrical bore

• C3 internal clearance

• cage design

• required load ratings

• operating speed

• lubrication conditions

• operating temperature

• shaft and housing fits

Matching the 35x72x17 mm dimensions alone does not guarantee complete interchangeability.

Installation

Before installation, inspect the shaft, housing and bearing contact surfaces.

Mounting forces should not be transmitted through the rolling elements. The appropriate installation method depends on the fits and design of the bearing arrangement.

Particular attention should be paid to:

• cleanliness

• correct shaft and housing fits

• alignment

• appropriate lubricant

• condition of raceways and rolling elements

• required operating clearance

Correct installation is essential for achieving the intended bearing performance and service life.

FAQ - FAG 20207-TVP-C3

What are the dimensions of FAG 20207-TVP-C3?

The bearing has a 35 mm bore diameter, 72 mm outside diameter and 17 mm width. Its nominal dimensions are 35x72x17 mm.

What type of bearing is 20207-TVP-C3?

It is a single-row spherical roller bearing.

What does TVP mean in FAG 20207-TVP-C3?

TVP identifies a solid cage manufactured from polyamide.

What does C3 mean?

C3 indicates internal clearance greater than Normal.

Does FAG 20207-TVP-C3 have a tapered bore?

No. FAG 20207-TVP-C3 has a cylindrical bore. The tapered-bore version is designated 20207-K-TVP-C3.

Is FAG 20207-TVP-C3 an open bearing?

Yes. It is an open bearing without integrated seals.

Can FAG 20207-TVP-C3 accommodate misalignment?

Yes. Its spherical roller bearing design allows it to accommodate angular misalignment between the shaft and housing within the limits applicable to this bearing type and operating arrangement.

Can any 35x72x17 mm bearing replace FAG 20207-TVP-C3?

No. Dimensions are only one selection criterion. Bearing type, cylindrical bore, C3 clearance, cage design, load requirements and operating conditions must also be considered.

FAG 20207-TVP-C3 - key information

FAG 20207-TVP-C3 is a single-row spherical roller bearing with dimensions 35x72x17 mm, a cylindrical bore, TVP solid polyamide cage and increased C3 internal clearance. Its self-aligning design allows it to accommodate angular misalignment between the shaft and housing while primarily supporting radial loads.
