F8-16M EZO 8x16x5 mm - Miniature Thrust Ball Bearing
17 pcs.
€2.80
(net)
Price for: 1pcs.
EZO F8-16M is a miniature thrust ball bearing with dimensions 8x16x5 mm, designed primarily for axial loads. It has an 8 mm bore, 16 mm outside diameter and 5 mm height. Dynamic axial load rating Ca is 3920 N and static axial load rating C0a is 4990 N. The bearing contains nine 3.0 mm balls. F8-16M is a thrust bearing, not a flanged radial deep groove ball bearing. Available from simmering.pl - stock in Poland with worldwide shipping.
Cage: TP - plastic cage, ball guided.
F8-16M EZO 8x16x5 mm - Miniature Thrust Ball Bearing
EZO F8-16M is a miniature thrust ball bearing with dimensions 8x16x5 mm, designed primarily to accommodate axial loads. It has an 8 mm bore, 16 mm outside diameter and 5 mm height. This is an open thrust-bearing design and should not be confused with a radial deep groove ball bearing of the same basic dimensions.
Technical data
| Parameter | Value |
|---|---|
| Manufacturer | EZO |
| Full designation | F8-16M |
| Bearing type | Thrust ball bearing |
| Design | Miniature, metric |
| Bore diameter d | 8 mm |
| Outside diameter D | 16 mm |
| Height H | 5 mm |
| d1 | 8.2 mm |
| D1 | 15.8 mm |
| Dynamic axial load rating Ca | 3920 N |
| Static axial load rating C0a | 4990 N |
| Limiting speed, oil lubrication | 16000 min-1 |
| Balls | 9 pcs., 3.0 mm diameter |
| Reference mass | 3.94 g |
| Closure | Open |
EZO F8-16M dimensions
The basic dimensions are:
d: 8 mm
D: 16 mm
H: 5 mm
Complete dimensional specification:
8x16x5 mm
Additional dimensions specified for this bearing are:
d1: 8.2 mm
D1: 15.8 mm
What does F8-16M mean?
F8-16M is the EZO designation for a miniature metric thrust ball bearing with basic dimensions 8x16x5 mm.
In this particular designation, F should not be interpreted as a flange designation for a radial miniature bearing. F8-16M belongs to the thrust-bearing range and is designed for axial rather than primarily radial loading.
The complete designation should therefore be retained when identifying or selecting a replacement.
Construction and operating principle
EZO F8-16M is a miniature thrust ball bearing designed primarily to accommodate axial loads.
Its rolling elements consist of 9 balls with a diameter of 3.0 mm.
The specified axial load ratings are:
Ca: 3920 N
C0a: 4990 N
Ca represents the basic dynamic axial load rating, while C0a represents the basic static axial load rating.
This bearing should not be treated as a conventional radial deep groove ball bearing simply because another bearing may share the same 8x16x5 mm envelope dimensions.
F8-16M vs 688
Although both bearings may have basic dimensions of 8x16x5 mm, they represent fundamentally different bearing constructions.
F8-16M EZO - miniature thrust ball bearing designed primarily for axial loading.
688 EZO - deep groove ball bearing designed primarily for radial loading while also being capable of carrying axial load within its design limits.
Matching dimensions therefore do not mean that F8-16M and 688 are interchangeable.
Load ratings of EZO F8-16M
The specified load ratings are:
Dynamic axial load rating Ca: 3920 N
Static axial load rating C0a: 4990 N
These values apply specifically to the EZO F8-16M and should not be transferred to visually similar bearings or products from other manufacturers.
Limiting speed
The specified limiting speed with oil lubrication is:
16000 min-1
The permissible operating speed in a particular application can be lower depending on load, lubrication, mounting conditions, temperature and the design of the complete bearing arrangement.
Selection and interchangeability
Before selecting EZO F8-16M, verify:
- complete F8-16M designation,
- thrust ball bearing construction,
- 8 mm bore,
- 16 mm outside diameter,
- 5 mm height,
- direction of the applied load,
- required axial load capacity,
- operating speed,
- lubrication conditions,
- design of the mating components.
A replacement should never be selected solely because it has dimensions of 8x16x5 mm.
Installation and operation
Cleanliness is particularly important when installing a miniature thrust bearing.
The bearing components must be correctly positioned relative to the direction of the axial load. Mating surfaces should be properly prepared, and uncontrolled mounting force should not be transmitted through the rolling elements.
Because of the bearing's miniature dimensions, accurate alignment and careful handling are particularly important.
Alternative designations and reference formats
- EZO F8-16M
- F8-16M EZO
- F 8-16M EZO
- EZO F 8-16M
- F8-16M 8x16x5
- EZO F8-16M 8x16x5
The complete manufacturer designation F8-16M is the preferred reference when identifying the product.
FAQ - EZO F8-16M
What are the dimensions of EZO F8-16M?
The bearing measures 8x16x5 mm, with an 8 mm bore, 16 mm outside diameter and 5 mm height.
What type of bearing is EZO F8-16M?
It is a miniature thrust ball bearing designed primarily to accommodate axial loads.
Is F8-16M a flanged deep groove ball bearing?
No. F8-16M is a thrust ball bearing. It should not be confused with EZO miniature radial bearings where an F designation may be associated with a flanged design.
What is the dynamic load rating of F8-16M?
The dynamic axial load rating Ca is 3920 N.
What is the static load rating of F8-16M?
The static axial load rating C0a is 4990 N.
How many balls does EZO F8-16M have?
The bearing has 9 balls with a diameter of 3.0 mm.
Are F8-16M and 688 the same bearing?
No. Although both may have basic dimensions of 8x16x5 mm, F8-16M is a thrust ball bearing, while 688 is a radial deep groove ball bearing.
Can another 8x16x5 mm bearing replace F8-16M?
Not automatically. The bearing type, direction of load, load ratings, speed and complete construction must also be verified.
F8-16M EZO - key information
EZO F8-16M 8x16x5 mm is a miniature thrust ball bearing designed primarily for axial loads. It has an 8 mm bore, 16 mm outside diameter and 5 mm height. Its dynamic axial load rating Ca is 3920 N, static axial load rating C0a is 4990 N, and it contains nine 3.0 mm balls.
Available from simmering.pl, a specialist supplier of bearings and industrial components. Stock in Poland with worldwide shipping.
EZO F8-16M is a miniature thrust ball bearing with dimensions 8x16x5 mm, designed primarily for axial loads. It has an 8 mm bore, 16 mm outside diameter and 5 mm height. Dynamic axial load rating Ca is 3920 N and static axial load rating C0a is 4990 N. The bearing contains nine 3.0 mm balls. F8-16M is a thrust bearing, not a flanged radial deep groove ball bearing. Available from simmering.pl - stock in Poland with worldwide shipping.
Cage: TP - plastic cage, ball guided.
