EZO F6-14M is a miniature single-direction thrust ball bearing with dimensions 6x14x5 mm, designed primarily to accommodate axial loads. It has a 6 mm bore, 14 mm outside diameter and 5 mm height. It is an open, separable bearing made from bearing steel and equipped with a steel cage guided by the rolling elements.

Technical data

EZO F6-14M dimensions

Basic dimensions:

d: 6 mm
D: 14 mm
H: 5 mm

Complete dimensional specification:

6x14x5 mm

F6-14M belongs to the miniature thrust bearing range and is designed for compact mechanisms requiring axial load support.

What does F6-14M mean?

F6-14M is the EZO designation for a miniature thrust ball bearing with dimensions 6x14x5 mm.

In this bearing series, the F should not be interpreted as a flange designation, as it may be in certain EZO miniature radial bearing designations.

F6-14M is a thrust bearing, not a flanged radial deep groove ball bearing.

EZO F6-14M construction

The bearing is designed primarily to accommodate axial loads. Its construction consists of thrust washers and a ball-and-cage assembly.

The bearing is:

• miniature,
• ball type,
• thrust type,
• single direction,
• open,
• separable.

The separable construction allows the bearing components to be mounted individually, but their correct orientation must be maintained during assembly.

Cage in EZO F6-14M

EZO F6-14M is equipped with a:

steel cage guided by the rolling elements.

The cage design is an important construction feature when identifying the correct bearing and evaluating potential replacements.

Axial load capability

F6-14M is designed primarily to accommodate axial loads in one direction.

It should not be treated as a radial bearing. If significant radial loads are present in the application, a suitable radial bearing arrangement must be provided separately.

Open construction

EZO F6-14M does not have seals or metal shields.

The open construction means that the complete bearing arrangement must take into account:

• lubrication,
• protection against contamination,
• cleanliness during installation,
• environmental conditions.

F6-14M vs radial ball bearing

Matching bore or outside diameter does not make a radial bearing interchangeable with F6-14M.

F6-14M is a thrust bearing designed primarily for axial loads.

A conventional deep groove ball bearing is designed primarily for radial loads, while also being capable of carrying a certain level of axial load.

These are fundamentally different bearing constructions and should not be interchanged solely on the basis of dimensions.

Dimensional equivalents

Bearings with the same basic 6x14x5 mm dimensions may be found under designations such as:

• AKL6 INA
• BA6 SKF
• B6 ADR
• B614 RMB

Matching dimensions alone do not confirm complete interchangeability. Bearing construction, load ratings, tolerances and application requirements must also be checked.

Selection and interchangeability

Before selecting EZO F6-14M, verify:

• complete F6-14M designation,
• dimensions 6x14x5 mm,
• single-direction thrust construction,
• direction of the applied load,
• required axial load capacity,
• operating speed,
• lubrication conditions,
• mating surfaces,
• available installation space.

A replacement should not be selected solely on the basis of its dimensions.

Installation

Cleanliness and correct component orientation are particularly important when installing a miniature thrust bearing.

The mating surfaces should provide proper support for the bearing washers. Because of the miniature dimensions, impacts, misalignment and excessive mounting force should be avoided.

Alternative designations and reference formats

• F6-14M EZO
• EZO F6-14M
• F 6-14 M EZO
• EZO F 6-14 M
• F6-14M 6x14x5
• EZO F6-14M 6x14x5
• F 6-14 M 6x14x5

For unambiguous product identification, the complete designation F6-14M EZO should be used.

FAQ - EZO F6-14M

What are the dimensions of EZO F6-14M?

The bearing measures 6x14x5 mm, with a 6 mm bore, 14 mm outside diameter and 5 mm height.

What type of bearing is F6-14M?

It is a miniature single-direction thrust ball bearing.

What loads does F6-14M accommodate?

The bearing is designed primarily to accommodate axial loads in one direction.

What cage does EZO F6-14M use?

F6-14M uses a steel cage guided by the rolling elements.

Is EZO F6-14M sealed?

No. It is an open bearing without seals or shields.

Is F6-14M a separable bearing?

Yes. Its thrust-bearing construction is separable, so the components must be correctly positioned during installation.

Does F in F6-14M mean flanged?

No. In this designation, F should not be interpreted as a flange. F6-14M is a miniature thrust ball bearing.

Can INA AKL6 replace EZO F6-14M?

Both designations may be found for thrust bearings with basic dimensions of 6x14x5 mm, but complete technical specifications and application requirements must be checked before substitution.

EZO F6-14M - key information

EZO F6-14M 6x14x5 mm is a miniature single-direction thrust ball bearing designed primarily for axial loads. It has a 6 mm bore, 14 mm outside diameter and 5 mm height. The bearing has an open, separable construction and uses a steel cage guided by the rolling elements.
