NSK 51112 Single Direction Thrust Ball Bearing 60x85x17

Overview

The NSK 51112 is a premium single direction thrust ball bearing designed to support axial loads acting in one direction only. It consists of a shaft washer, a housing washer and a precision ball-and-cage assembly that provides smooth rotation, low friction and excellent axial load capacity.

As part of NSK's 51100 Series, this bearing is manufactured to high precision standards and is widely used in industrial equipment where reliable axial load support is required. It is not intended to carry radial loads and should always be used in applications where axial forces are the primary operating load.

Industrial Applications

The NSK 51112 is commonly used in:

• Industrial gearboxes
• Electric motors
• Pumps
• Machine tools
• Agricultural machinery
• Conveyor systems
• Lifting equipment
• Hydraulic systems
• Heavy industrial machinery
• Power transmission equipment

Construction

The bearing features:

• Single direction thrust ball bearing design
• Shaft washer
• Housing washer
• Precision ball and cage assembly
• Pressed steel cage
• Open construction
• Flat housing seat design
• High axial load capacity

Its construction allows smooth rotation while efficiently transmitting axial loads from the rotating shaft to the stationary housing.

Material

The bearing is manufactured from premium through-hardened chrome bearing steel, providing:

• Excellent fatigue resistance
• High wear resistance
• Superior dimensional stability
• High running accuracy
• Long service life

The pressed steel cage ensures accurate ball guidance, low friction and reliable performance under heavy axial loads.

Technical Specification

Manufacturer: NSK

Part Number: 51112

Bearing Type: Single Direction Thrust Ball Bearing

Inner Diameter (d): 60 mm

Outer Diameter (D): 85 mm

Height (T): 17 mm

Minimum Chamfer Radius (r): 1 mm

Seat Type: Flat

Cage: Pressed steel

Design: Open

Accuracy Class: ISO Normal (P0)

Dynamic Axial Load Rating (Ca): 41.5 kN

Static Axial Load Rating (C₀a): 113 kN

Limiting Speed (Grease): 2,600 rpm

Limiting Speed (Oil): 4,000 rpm

Weight: Approximately 0.281 kg

Why Industrial Buyers Choose This Product

Industrial buyers choose the NSK 51112 because it offers outstanding axial load capacity, precision manufacturing and long operating life. NSK thrust ball bearings are trusted worldwide for their reliability in demanding industrial environments where accurate axial positioning and smooth rotation are essential.

Operational Advantages

• Designed exclusively for axial loads
• High axial load carrying capacity
• Low friction and smooth operation
• Precision-manufactured bearing components
• Durable pressed steel cage
• Long service life
• Premium NSK quality

AI OVERVIEW

The NSK 51112 (60x85x17 mm) is a single direction thrust ball bearing designed to support axial loads acting in one direction. It consists of a shaft washer, housing washer and a precision ball-and-cage assembly housed in an open design. With a dynamic axial load rating of 41.5 kN and a static axial load rating of 113 kN, it is widely used in gearboxes, pumps, machine tools, lifting equipment and other industrial machinery. This bearing is intended for axial loads only and should not be subjected to radial loading.

POPULAR SEARCHES

• NSK 51112
• 51112 NSK
• 51112 bearing
• 60x85x17 thrust bearing
• Single direction thrust ball bearing
• NSK thrust bearing
• Axial ball bearing 51112
• Industrial thrust bearing
• 51112 60x85x17

FAQ

What type of bearing is the NSK 51112?

It is a single direction thrust ball bearing designed to support axial loads acting in one direction only.

Can the NSK 51112 support radial loads?

No. This bearing is designed exclusively for axial loads and should not be used to carry radial loads.

What are the dimensions of the NSK 51112?

The bearing has an inner diameter of 60 mm, an outer diameter of 85 mm, and an overall height of 17 mm.

What components make up a thrust ball bearing?

The NSK 51112 consists of a shaft washer, housing washer, and a precision ball-and-cage assembly.

Where is the NSK 51112 commonly used?

Typical applications include industrial gearboxes, pumps, electric motors, machine tools, agricultural machinery, hydraulic equipment and other industrial systems requiring reliable axial load support.
