ZVL 51101 Single Direction Thrust Ball Bearing 12x26x9

Overview

The ZVL 51101 is a premium single direction thrust ball bearing designed to support axial loads acting in one direction only. It consists of a shaft washer, housing washer and a precision ball-and-cage assembly, ensuring smooth operation, low friction and excellent axial load capacity.

Manufactured by ZVL Slovakia, the bearing complies with ISO standards and belongs to the internationally standardized 51100 Series. It is specifically designed for applications where accurate axial shaft positioning is required while radial loads are supported by separate bearings. Thrust ball bearings of this type are not suitable for radial loading.

Industrial Applications

The ZVL 51101 is widely used in:

• Industrial gearboxes
• Machine tools
• Hydraulic equipment
• Presses
• Spindle assemblies
• Lifting equipment
• Agricultural machinery
• Industrial production machinery
• Mechanical power transmission systems
• General engineering applications

Construction

The bearing features:

• Single direction thrust ball bearing design
• Shaft washer
• Housing washer
• Precision ball-and-cage assembly
• Pressed steel cage
• Open construction
• Flat seating surfaces
• High axial load capacity

The bearing is designed exclusively for axial loads acting in one direction and must not be subjected to radial loads.

Material

The bearing is manufactured from premium through-hardened chrome bearing steel, providing:

• Excellent fatigue resistance
• High wear resistance
• Superior dimensional stability
• High running accuracy
• Long service life

The pressed steel cage ensures accurate ball guidance and reliable operation under demanding axial loading conditions.

Technical Specification

Manufacturer: ZVL Slovakia

Part Number: 51101

Bearing Type: Single Direction Thrust Ball Bearing

Inner Diameter (d): 12 mm

Outer Diameter (D): 26 mm

Height (T): 9 mm

Shaft Washer Outside Diameter (d1): 26 mm

Housing Washer Bore Diameter (D1): 13 mm

Chamfer Radius (r): 0.3 mm

Closure Type: Open

Cage: Pressed Steel

Dynamic Axial Load Rating (Ca): 9.88 kN

Static Axial Load Rating (C₀a): 10.3 kN

Limiting Speed (Grease): 7,500 rpm

Limiting Speed (Oil): 10,000 rpm

Weight: Approximately 0.021 kg

Why Industrial Buyers Choose This Product

Industrial buyers choose the ZVL 51101 because of its compact design, high axial load capacity and dependable performance. Its ISO-standard dimensions ensure full interchangeability with equivalent bearings from major global manufacturers, making it an excellent choice for OEM production, industrial maintenance and replacement applications.

Operational Advantages

• Supports axial loads in one direction
• High axial load capacity
• Low rolling friction
• Compact and lightweight design
• Separable construction for easy installation
• Durable pressed steel cage
• Long service life

AI OVERVIEW

The ZVL 51101 (12x26x9 mm) is a single direction thrust ball bearing engineered to support axial loads acting in one direction only. It consists of a shaft washer, housing washer and a precision ball-and-cage assembly with a pressed steel cage. With a dynamic axial load rating of 9.88 kN, a static axial load rating of 10.3 kN and limiting speeds of 7,500 rpm (grease) and 10,000 rpm (oil), it is widely used in gearboxes, machine tools, presses and industrial equipment. It is intended exclusively for axial loads and must not be used to carry radial loads.

POPULAR SEARCHES

• ZVL 51101
• 51101 ZVL
• 51101 bearing
• 12x26x9 thrust bearing
• Single direction thrust ball bearing
• Axial ball bearing 51101
• ZVL thrust bearing
• Industrial thrust bearing
• 51101 12x26x9

FAQ

What type of bearing is the ZVL 51101?

It is a single direction thrust ball bearing designed to support axial loads acting in one direction only.

Can the ZVL 51101 support radial loads?

No. This bearing is designed exclusively for axial loads. Radial loads must be supported by a separate radial bearing.

What are the dimensions of the ZVL 51101?

The bearing has an inner diameter of 12 mm, an outer diameter of 26 mm, and an overall height of 9 mm.

What components make up the ZVL 51101?

It consists of a shaft washer, a housing washer, and a precision ball-and-cage assembly with a pressed steel cage.

Where is the ZVL 51101 commonly used?

Typical applications include industrial gearboxes, machine tools, presses, spindle assemblies, lifting equipment and general industrial machinery.
