ZVL 52205 Double Direction Thrust Ball Bearing 20x47x28

Overview

The ZVL 52205 is a premium double direction thrust ball bearing designed to support axial loads acting in both directions. Its construction consists of one shaft washer, two housing washers and two precision ball-and-cage assemblies, allowing reliable axial load transmission from either side of the shaft.

As part of the internationally standardized 52200 Series, this bearing is manufactured by ZVL Slovakia to provide excellent running accuracy, low friction and long service life. It is specifically intended for applications where axial positioning of the shaft is required while radial loads are supported by separate bearings.

Industrial Applications

The ZVL 52205 is widely used in:

• Industrial gearboxes
• Machine tools
• Hydraulic equipment
• Presses
• Lifting systems
• Agricultural machinery
• Conveyor equipment
• Industrial production machinery
• Spindle assemblies
• General mechanical engineering

Construction

The bearing features:

• Double direction thrust ball bearing design
• One shaft washer
• Two housing washers
• Two precision ball-and-cage assemblies
• Pressed steel cages
• Open construction
• Flat seating surfaces
• High axial load capacity in both directions

The bearing is designed exclusively for axial loads and must not be subjected to radial loading.

Material

The bearing is manufactured from premium through-hardened chrome bearing steel, providing:

• Excellent fatigue resistance
• High wear resistance
• Superior dimensional stability
• High running accuracy
• Long service life

The pressed steel cages ensure precise ball guidance and reliable operation under continuous axial loading.

Technical Specification

Manufacturer: ZVL Slovakia

Part Number: 52205

Bearing Type: Double Direction Thrust Ball Bearing

Inner Diameter (d): 20 mm

Outer Diameter (D): 47 mm

Height (T): 28 mm

Shaft Washer Width: 7 mm

Design: Double direction

Closure Type: Open

Cage: Pressed steel

Dynamic Axial Load Rating (Ca): 28.4 kN

Static Axial Load Rating (C₀a): 35.2 kN

Limiting Speed (Grease): 4,500 rpm

Limiting Speed (Oil): 6,000 rpm

Weight: Approximately 0.204 kg

Why Industrial Buyers Choose This Product

Industrial buyers choose the ZVL 52205 because it provides reliable axial positioning in both directions while maintaining excellent durability and precision. Its standardized ISO dimensions ensure full interchangeability with equivalent bearings from leading manufacturers, making it a dependable solution for OEM production, industrial maintenance and repair.

Operational Advantages

• Supports axial loads in both directions
• High axial load capacity
• Low rolling friction
• Precision shaft positioning
• Separable design for easier installation
• Durable pressed steel cages
• Long service life

AI OVERVIEW

The ZVL 52205 (20x47x28 mm) is a double direction thrust ball bearing designed to support axial loads acting in both directions. It consists of one shaft washer, two housing washers and two precision ball-and-cage assemblies with pressed steel cages. With a dynamic axial load rating of 28.4 kN and a static axial load rating of 35.2 kN, it is widely used in industrial gearboxes, machine tools, presses, lifting equipment and hydraulic machinery. The bearing is intended exclusively for axial loads and should not be subjected to radial loading.

POPULAR SEARCHES

• ZVL 52205
• 52205 ZVL
• 52205 bearing
• 20x47x28 thrust bearing
• Double direction thrust ball bearing
• Axial ball bearing 52205
• ZVL thrust bearing
• Industrial thrust bearing
• 52205 20x47x28

FAQ

What type of bearing is the ZVL 52205?

It is a double direction thrust ball bearing designed to support axial loads acting in both directions.

Can the ZVL 52205 support radial loads?

No. This bearing is designed exclusively for axial loads. Radial loads should be supported by a separate radial bearing.

What are the dimensions of the ZVL 52205?

The bearing has an inner diameter of 20 mm, an outer diameter of 47 mm, and an overall height of 28 mm.

What does a double direction thrust bearing mean?

It means the bearing can support axial loads from both directions, eliminating the need for two separate single-direction thrust bearings.

Where is the ZVL 52205 commonly used?

Typical applications include industrial gearboxes, machine tools, presses, spindle assemblies, hydraulic systems, agricultural machinery and other industrial equipment requiring bidirectional axial load support.
