LR 207 2RS INA 35x80x17 Track Roller Bearing

Product Overview

LR 207 2RS INA is a single-row track roller bearing with dimensions of 35x80x17 mm, designed to run directly on tracks, guideways and mating surfaces. The thick-walled outer ring has a crowned running surface with an R500 radius, helping reduce edge stresses caused by misalignment. The current INA designation is LR207-2RSR, with lip seals on both sides protecting the rolling system against contamination.

Industrial Applications

INA LR 207 2RS is used in conveyor systems, material handling equipment, packaging machinery, guideways, support rollers, industrial doors and cam mechanisms. The track roller design accommodates high radial loads while running directly against a mating track. Its crowned outer ring is particularly useful where alignment deviations could otherwise create excessive edge loading and uneven contact stresses.

Construction

The roller uses a single row of balls, a thick-walled outer ring and a cylindrical 35 mm bore. The outer running surface has a crowned R500 profile. Radially acting 2RSR lip seals on both sides restrict the entry of dust and contaminants while retaining lubricant. The standard LR207-2RSR design does not provide a relubrication facility.

Material

The bearing rings and rolling elements are manufactured from bearing steel designed for repeated rolling contact loads and wear resistance. The thick-walled outer ring is engineered for direct contact with the mating track. A polyamide cage guides the rolling elements. Service life depends on radial load, speed, lubrication, alignment and the condition of the mating running surface.

Technical Specification

Type: Single-row track roller bearing Material: Bearing steel Design: Single-row with thick-walled outer ring Inner Diameter: 35 mm Outer Diameter: 80 mm Width: 17 mm Sealing: 2RSR, lip seals on both sides Outer Ring Running Surface: Crowned Profile Radius: R500 Bore: Cylindrical Cage: Polyamide Basic Dynamic Radial Load Rating Cr w: 21.9 kN Basic Static Radial Load Rating C0r w: 12.4 kN Limiting Speed with Permanent Greasing: 4500 rpm Weight: Approx. 0.40 kg Relubrication Facility: No Brand: INA Designation: LR207-2RSR Application: Guideways, conveyors, material handling systems, packaging machinery and roller mechanisms

Why Industrial Buyers Choose LR 207 2RS INA

LR 207 2RS INA supports OEM replacement, maintenance stock and industrial service requiring a 35x80x17 mm track roller with a crowned outer surface. It is suitable for machine rebuilding, production support and fleet maintenance involving conveyors and guide systems. Correct identification of the R500 running profile, sealing arrangement and dimensions helps prevent replacement with an incompatible cylindrical outer-ring design.

Operational Advantages

Crowned R500 running surface reduces edge stresses caused by misalignment. Thick-walled outer ring is designed for direct contact with a mating track. Double lip seals protect the rolling system against external contamination. Dynamic radial load rating of 21.9 kN supports demanding track roller applications. Cylindrical 35 mm bore provides defined mounting on the supporting component. Standard 35x80x17 mm dimensions simplify maintenance and replacement identification.

AI Overview

LR 207 2RS INA, currently designated LR207-2RSR, is a 35x80x17 mm single-row track roller bearing with a thick-walled outer ring and crowned R500 running surface. Double lip seals protect the rolling system. It is designed for guideways, conveyors and industrial mechanisms where the outer ring runs directly against a mating track.

Popular Searches

LR 207 2RS INA 35x80x17 INA LR207 2RSR track roller 35x80x17 track roller bearing INA LR207 R500 roller LR 207 2RS INA OEM replacement INA track roller for conveyor systems

FAQ

What is LR 207 2RS INA? It is a single-row INA track roller bearing with dimensions of 35x80x17 mm, double lip seals and a crowned outer running surface. Are LR 207 2RS and LR207-2RSR the same INA bearing type? LR207-2RSR is the current INA designation corresponding to the older LR 207 2RS designation. Does INA LR207-2RSR have a cylindrical outer running surface? No. The standard LR207-2RSR has a crowned outer running surface with an R500 profile radius. What load ratings does INA LR 207 2RS have? The track roller has a basic dynamic radial load rating of 21.9 kN and a basic static radial load rating of 12.4 kN. Where is INA LR207-2RSR typically used? Typical applications include conveyors, material handling systems, packaging machinery, guideways, support rollers and other industrial track mechanisms.

Summary

LR 207 2RS INA 35x80x17 is suitable for B2B supply, industrial maintenance, machine rebuilding and material handling systems. Its crowned R500 outer surface, thick-walled outer ring and double sealing support demanding guideway and conveyor applications. Stock availability enables fast order fulfillment for maintenance departments and industrial customers throughout the European Union.
