SKF FYC 40 TF 40 mm Round Flanged Bearing Unit
Processing time: 2-3 days
€37.69
(net)
Price for: 1pcs.
Warehouse and Store: Lublin
The SKF FYC 40 TF is supplied by simmering.pl for industrial maintenance, machinery service, OEM applications and B2B customers.
SKF FYC 40 TF is a round flanged insert bearing unit for a 40 mm shaft, using a YAR 208-2F insert bearing with set-screw locking. SKF catalogue data specifies an overall width of 51.2 mm and a 120 mm pitch circle diameter. The corresponding bearing size provides a 30.7 kN basic dynamic load rating and 19.0 kN basic static load rating. Its cast iron, self-aligning and relubricatable construction makes it suitable for industrial machinery, conveyors and shaft-support applications.
SKF FYC 40 TF is a complete round flanged insert bearing unit for a 40 mm shaft. It combines a cast iron round flange housing with an SKF YAR 208-2F insert bearing. The bearing is secured directly to the shaft by set screws. SKF catalogue data identifies FYC 40 TF as a round flanged unit with a 40 mm bore, 51.2 mm width and 120 mm pitch circle diameter.
Technical Specifications
Manufacturer: SKF
Designation: FYC 40 TF
Product type: Round flanged insert bearing unit
Shaft diameter d: 40 mm
Insert bearing: YAR 208-2F
Housing type: Round flange
Housing material: Cast iron
Bore: Cylindrical
Shaft locking: Set screws
Sealing: Contact seals with additional flingers
Seal type: 2F
Lubrication: Grease
Relubrication: Yes
Number of mounting holes: 4
Overall unit width: 51.2 mm
Pitch circle diameter: 120 mm
SKF's designation system confirms that TF identifies a unit fitted with a YAR 2-2F series bearing with grub/set-screw locking.
SKF FYC 40 TF Load Ratings
The YAR 208-2F bearing size used in this unit has the following catalogue load ratings:
Basic dynamic load rating C: 30.7 kN
Basic static load rating C0: 19.0 kN
These values correspond to the SKF 208 bearing size used in the YAR 208 family.
YAR 208-2F Insert Bearing
The YAR 208-2F is a self-aligning insert ball bearing with a 40 mm cylindrical bore and an extended inner ring.
The inner ring is locked directly onto the shaft using set screws. This eliminates the need for an adapter sleeve and provides a straightforward mounting method for industrial machinery.
The 2F sealing system combines contact sealing with additional flingers to improve protection against contamination while retaining lubricant inside the bearing.
Round Flange Housing
The FYC design uses a round four-bolt flange housing. SKF lists the FYC 40 TF with:
Shaft diameter: 40 mm
Overall width: 51.2 mm
Pitch circle diameter: 120 mm
Seal type: 1-lip 2F.
These mounting dimensions are particularly important when selecting a replacement bearing unit.
Self-Aligning Design
The spherical outside surface of the insert bearing operates in a correspondingly shaped housing seat.
This design enables the bearing unit to accommodate limited initial misalignment between the shaft and housing, making mounted bearing units suitable for many industrial shaft-support arrangements.
Shaft Locking
SKF FYC 40 TF uses set-screw shaft locking.
The extended inner ring of the YAR 208-2F is secured directly to the 40 mm shaft. SKF's designation documentation explicitly defines TF as a YAR 2-2F series bearing with grub-screw locking.
Operational Advantages
- Complete ready-to-mount bearing unit
- 40 mm cylindrical shaft mounting
- Direct set-screw locking
- Self-aligning insert bearing design
- Cast iron flange housing
- Relubricatable construction
Typical Applications
SKF FYC 40 TF is suitable for appropriately designed conveyors, agricultural machinery, material handling equipment, production machinery, industrial drives and mechanical transmission systems.
Final selection should consider load, shaft speed, temperature, lubrication, contamination and mounting conditions.
How to Select an SKF FYC 40 TF Replacement
Verify the following parameters:
Designation: FYC 40 TF
Manufacturer: SKF
Shaft diameter: 40 mm
Unit type: Round flanged bearing unit
Insert: YAR 208-2F
Locking: Set screws
Housing: Cast iron
Overall width: 51.2 mm
Pitch circle diameter: 120 mm
Dynamic load rating: 30.7 kN
Static load rating: 19.0 kN.
FAQ - Technical Questions
What shaft diameter is SKF FYC 40 TF designed for?
It is designed for a 40 mm shaft.
What type of bearing unit is FYC 40 TF?
It is an SKF round flanged insert bearing unit.
Which insert bearing is used?
The TF execution uses a bearing from the YAR 2-2F series; for the 40 mm size this is YAR 208-2F.
How is FYC 40 TF secured to the shaft?
The insert bearing is locked directly onto the shaft using set screws.
What is the mounting pitch circle diameter?
The PCD is 120 mm.
What is the overall width?
SKF specifies 51.2 mm.
What is the basic dynamic load rating?
The corresponding 208 bearing size has a basic dynamic load rating of 30.7 kN.
What is the basic static load rating?
The basic static load rating is 19.0 kN.
