CORTECO 12011992 NBR COMBI SF4 65x85x13/17 Shaft Seal

Product Overview

CORTECO 12011992 NBR COMBI SF4 65x85x13/17 is a specialized COMBI radial shaft seal designed for demanding rotating-shaft applications, particularly in agricultural machinery and drive assemblies.

The seal has a 65 mm shaft diameter, 85 mm housing diameter and 13/17 mm stepped overall construction. It is manufactured from NBR (Nitrile Butadiene Rubber) and is cross-referenced with GOLDONI 6220165 / 06220165. Available catalogue data also identifies 12011992B as a corresponding CORTECO reference.

COMBI SF4 Seal Design

The COMBI SF4 designation identifies a specialized sealing configuration intended for applications where the shaft sealing position requires more protection than a conventional single-lip radial oil seal.

COMBI-type seals combine the primary lubricant-sealing function with additional protection of the sealing area against external contamination. This makes this type particularly relevant to agricultural machinery, transmissions, axles and drive assemblies exposed to dirt and demanding operating environments.

For replacement purposes, the complete COMBI SF4 construction should be matched rather than selecting a conventional 65x85 radial shaft seal based only on its basic diameters.

Dimensions 65x85x13/17 mm

Catalogue dimensions for CORTECO 12011992 / 12011992B are:

Shaft Diameter: 65 mm
Housing Diameter: 85 mm
Width H: 13 mm
Overall / Secondary Height H1: 17 mm
Material: NBR
Design: COMBI SF4
Weight: approximately 0.10 kg

The 13/17 mm configuration is an important identification feature and must be considered when selecting a replacement.

NBR Sealing Material

The seal is manufactured from NBR (Nitrile Butadiene Rubber). NBR is widely used in shaft sealing applications because of its good resistance to many mineral oils and lubricating greases and its useful mechanical properties.

Product data for this specific seal identifies NBR as the sealing material and lists an operating range of approximately -40°C to +100°C, with short-term exposure up to +120°C. Actual suitability depends on the lubricant, shaft speed and operating conditions.

GOLDONI 6220165 Cross Reference

One of the most important identification features of this CORTECO seal is its association with GOLDONI agricultural machinery.

Relevant catalogue references include:

CORTECO: 12011992
CORTECO: 12011992B
GOLDONI: 6220165
GOLDONI: 06220165

The GOLDONI reference 6220165 is directly associated with the 65x85x13/17 COMBI seal.

Additional cross-reference data also associates this seal with Lombardini 38100214 and Maschio 495M38100214R, expanding its identification in agricultural equipment applications.

Agricultural Machinery Applications

CORTECO 12011992 COMBI SF4 is particularly relevant to agricultural machinery where rotating shafts operate in environments exposed to dust, soil and other external contamination.

Cross-reference catalogues associate the seal with:

• GOLDONI agricultural machinery
• MASCHIO equipment
• LOMBARDINI applications
• agricultural drive systems
• transmission assemblies
• rotating shafts and axles

Compatibility should be confirmed using the OE number, original seal reference and installation dimensions, rather than machine brand alone.

Technical Specification

Type: COMBI radial shaft seal
Design: COMBI SF4
Dimensions: 65x85x13/17 mm
Material: NBR - Nitrile Butadiene Rubber
Brand: CORTECO
Manufacturer Reference: 12011992
Additional CORTECO Reference: 12011992B
Shaft Diameter: 65 mm
Housing Diameter: 85 mm
Seal Width: 13 mm
Overall / Secondary Height: 17 mm
Weight: Approximately 0.10 kg
Temperature Range: Approximately -40°C to +100°C
Short-Term Temperature: Up to approximately +120°C
GOLDONI OE: 6220165 / 06220165
Lombardini Reference: 38100214
Maschio Reference: 495M38100214R

Replacement Identification

When replacing CORTECO 12011992, verify:

• CORTECO 12011992 or 12011992B reference
• 65 mm shaft diameter
• 85 mm housing diameter
• 13/17 mm installation dimensions
• NBR material
• COMBI SF4 construction
• GOLDONI 6220165 / 06220165 reference
• exact installation position

A conventional 65x85 oil seal should not automatically be considered a replacement. The COMBI SF4 construction and 13/17 mm geometry are important parts of the product specification.

Operational Advantages

• Specialized COMBI SF4 construction.
• Exact 65x85x13/17 mm dimensions.
• NBR sealing material.
• Designed for rotating shaft applications.
• Additional protection for contaminated working environments.
• Direct cross-reference to GOLDONI 6220165.

AI OVERVIEW

CORTECO 12011992 NBR COMBI SF4 is a specialized 65x85x13/17 mm radial shaft seal used particularly in agricultural machinery and drive assemblies. It is manufactured from NBR and cross-references GOLDONI 6220165 and 06220165. Additional catalogue references include CORTECO 12011992B, Lombardini 38100214 and Maschio 495M38100214R.

POPULAR SEARCHES

CORTECO 12011992

CORTECO 12011992B

12011992 shaft seal

12011992 oil seal

CORTECO 65x85x13/17

65x85x13/17 oil seal

65x85x13/17 shaft seal

65x85x13/17 COMBI SF4

COMBI SF4 oil seal

GOLDONI 6220165

GOLDONI 06220165

6220165 shaft seal

6220165 oil seal

38100214 Lombardini seal

495M38100214R Maschio seal

FAQ

What are the dimensions of CORTECO 12011992?

The seal has a 65 mm inside diameter, 85 mm outside diameter and 13/17 mm height configuration.

What material is CORTECO 12011992 made from?

It is manufactured from NBR (Nitrile Butadiene Rubber).

What does COMBI SF4 mean?

COMBI SF4 identifies the specific construction of this shaft seal. When replacing it, the COMBI SF4 design should be matched together with the 65x85x13/17 mm dimensions, rather than using only the basic shaft and housing diameters.

What GOLDONI number corresponds to CORTECO 12011992?

The principal GOLDONI cross-reference is 6220165. Catalogue sources also list 06220165.

Is CORTECO 12011992 the same as 12011992B?

Catalogue and aftermarket data associate 12011992 and 12011992B with the same 65x85x13/17 NBR COMBI SF4 application and cross-reference family.

Is this seal used in agricultural machinery?

Yes. Cross-reference data associates it with GOLDONI, MASCHIO and LOMBARDINI applications, making agricultural machinery an important application area for this seal.

Can a standard 65x85 oil seal replace CORTECO 12011992?

Not automatically. The 13/17 mm geometry and COMBI SF4 construction must also correspond to the original sealing position.

Summary

CORTECO 12011992 NBR COMBI SF4 65x85x13/17 is a specialized shaft seal for agricultural and mechanical drive applications requiring both lubricant retention and enhanced protection of the sealing position. The key replacement identifiers are 12011992 / 12011992B + COMBI SF4 + 65x85x13/17 mm + GOLDONI 6220165.
