CORTECO 12013927B 65x85x10 NBR BASLDRWX67 Wheel Hub Oil Seal

CORTECO 12013927B 65x85x10 NBR BASLDRWX67 Wheel Hub Oil Seal

CORTECO 12013927B is a wheel hub rotary shaft oil seal with exact dimensions of 65x85x10 mm. The sealing material is NBR - Nitrile Butadiene Rubber, and the exact CORTECO design designation is BASLDRWX67.

The seal incorporates an additional dust lip and Alternating Twist sealing geometry. Catalogue data specify applications at both the front axle and rear axle.

CORTECO 12013927B - Technical Specification

Manufacturer: CORTECO

Full reference: 12013927B

Base reference: 12013927

Trade Number: 82013927

Product type: Wheel hub oil seal

Fitting position: Front Axle / Rear Axle

Exact design: BASLDRWX67

Material: NBR - Nitrile Butadiene Rubber

Dimensions: 65x85x10 mm

Inside diameter d: 65 mm

Outside diameter D: 85 mm

Width B: 10 mm

Additional dust lip: Yes

Swirl Type: Alternating Twist

Fendt OE: X550132901000

Renault OE: 5000389751, 5000389994

Renault Trucks OE: 5010216174

Volkswagen OE: 291501317

EAN: 3358960340627

CORTECO 12013927B Dimensions

The exact dimensions are:

Inside diameter d: 65 mm

Outside diameter D: 85 mm

Width B: 10 mm

Complete dimensions: 65x85x10 mm

The 65 mm dimension corresponds to the nominal shaft diameter.

The 85 mm dimension corresponds to the outside diameter of the seal.

The 10 mm dimension corresponds to the seal width.

All three dimensions should be verified together with the NBR material, BASLDRWX67 design, dust lip and Alternating Twist geometry when identifying a replacement.

Matching the nominal 65x85x10 mm dimensions alone does not establish complete technical interchangeability.

BASLDRWX67 Oil Seal Design

Exact CORTECO design: BASLDRWX67

Reference: 12013927B

Dimensions: 65x85x10 mm

Material: NBR

Additional dust lip: Yes

Swirl Type: Alternating Twist

BASLDRWX67 is the exact CORTECO design designation associated with reference 12013927B.

The complete design code is an important technical identification parameter when comparing this seal with other 65x85x10 mm rotary shaft oil seals.

A seal with identical dimensions but a different design designation should not automatically be considered technically equivalent.

Additional Dust Lip

CORTECO 12013927B incorporates an additional dust lip.

The primary sealing lip performs the main sealing function, while the auxiliary dust lip forms an additional barrier on the external side of the main sealing area.

This configuration helps limit the ingress of external contamination toward the primary sealing zone.

The dust lip is a confirmed feature of this exact CORTECO reference and should be considered when selecting a replacement.

Alternating Twist Sealing Geometry

Swirl Type: Alternating Twist

CORTECO 12013927B incorporates directional sealing geometry specified as Alternating Twist.

This feature forms part of the complete BASLDRWX67 specification.

Alternating Twist should be distinguished from Left-hand Twist and Right-hand Twist configurations when comparing technically similar rotary shaft seals.

A seal with the same 65x85x10 mm dimensions but different directional sealing geometry should not automatically be considered equivalent.

NBR - Nitrile Butadiene Rubber

Material: NBR

Full material name: Nitrile Butadiene Rubber

NBR is the sealing material specified for CORTECO 12013927B.

The material forms part of the exact product specification together with the 65x85x10 mm dimensions, BASLDRWX67 design, additional dust lip and Alternating Twist geometry.

An FPM, ACM or other elastomer seal with identical dimensions should not automatically be considered technically interchangeable.

Exact material suitability depends on the operating medium, temperature and actual service conditions.

CORTECO 12013927B Wheel Hub Oil Seal

Product type: Wheel hub oil seal

Fitting position: Front Axle / Rear Axle

Dimensions: 65x85x10 mm

Material: NBR

Design: BASLDRWX67

Dust lip: Yes

Swirl Type: Alternating Twist

Current catalogue data classify CORTECO 12013927B as a Shaft Seal, wheel hub.

This application-specific identification is more precise than describing the product simply as a generic 65x85x10 mm rotary shaft seal.

CORTECO 12013927B Front and Rear Axle Applications

CORTECO 12013927B is catalogued for:

Fitting position: Front Axle

Fitting position: Rear Axle

The exact fitting position depends on the specific vehicle and axle configuration.

For vehicle-specific selection, the OE reference and exact application should therefore be checked rather than assuming the same installation position across all vehicles.

CORTECO 12013927B Fendt X550132901000

CORTECO reference: 12013927B

Fendt OE: X550132901000

Dimensions: 65x85x10 mm

Material: NBR

Design: BASLDRWX67

Fendt X550132901000 is a catalogue OE cross-reference associated with CORTECO 12013927B.

The OE reference provides an additional identification path for Fendt applications.

CORTECO 12013927B Renault 5000389751 5000389994

CORTECO reference: 12013927B

Renault OE: 5000389751

Renault OE: 5000389994

Dimensions: 65x85x10 mm

Material: NBR

Design: BASLDRWX67

Renault references 5000389751 and 5000389994 are catalogue OE cross-references associated with CORTECO 12013927B.

These references are useful for identifying the exact wheel hub seal in applicable Renault vehicles.

CORTECO 12013927B Renault Trucks 5010216174

CORTECO reference: 12013927B

Renault Trucks OE: 5010216174

Dimensions: 65x85x10 mm

Material: NBR

Design: BASLDRWX67

Renault Trucks 5010216174 is a confirmed OE cross-reference for CORTECO 12013927B.

For a specific Renault Trucks vehicle, the OE reference should be verified together with the exact axle configuration.

CORTECO 12013927B Volkswagen 291501317

CORTECO reference: 12013927B

Volkswagen OE: 291501317

Dimensions: 65x85x10 mm

Material: NBR

Design: BASLDRWX67

Volkswagen 291501317 is a catalogue OE cross-reference associated with CORTECO 12013927B.

The OE number provides an additional identification method for applicable Volkswagen applications.

12013927, 12013927B and 82013927

Base reference: 12013927

Full CORTECO reference: 12013927B

Trade Number: 82013927

Design: BASLDRWX67

EAN: 3358960340627

The full CORTECO product reference is 12013927B.

The base reference 12013927, Trade Number 82013927 and design designation BASLDRWX67 provide additional identifiers for catalogue searches and replacement identification.

CORTECO 12013927B vs Standard 65x85x10 Oil Seal

CORTECO 12013927B should not be identified solely as a standard 65x85x10 mm oil seal.

Its exact specification includes:

Dimensions: 65x85x10 mm

Material: NBR

Design: BASLDRWX67

Additional dust lip: Yes

Swirl Type: Alternating Twist

Product type: Wheel hub oil seal

Fitting position: Front Axle / Rear Axle

Two rotary shaft seals may have identical dimensions while differing in material, lip configuration, directional sealing geometry and application.

Matching dimensions alone therefore do not establish complete technical interchangeability.

CORTECO 12013927B vs CORTECO 01019923B

CORTECO 12013927B and CORTECO 01019923B both have nominal dimensions of 65x85x10 mm, but they are different products.

CORTECO 12013927B:

Material: NBR

Design: BASLDRWX67

Swirl Type: Alternating Twist

Application: Wheel hub

CORTECO 01019923B:

Material: ACM

Design: BASLRSX7

Swirl Type: Left-hand Twist

Application: Manual transmission

Identical dimensions therefore do not mean that these two CORTECO references are interchangeable.

How to Select a Replacement for CORTECO 12013927B

When selecting a replacement, verify:

Full reference: 12013927B

Base reference: 12013927

Trade Number: 82013927

Inside diameter: 65 mm

Outside diameter: 85 mm

Width: 10 mm

Material: NBR

Design: BASLDRWX67

Additional dust lip: Yes

Swirl Type: Alternating Twist

Fitting position: According to the specific application

OE reference: According to the specific vehicle

For vehicle-specific selection, the OE reference and exact axle configuration should take priority over selection based solely on dimensions.

CORTECO 12013927B - Stock in Poland

CORTECO 12013927B 65x85x10 NBR BASLDRWX67 Wheel Hub Oil Seal is available from stock in Poland.

Warehouse and Store: Lublin, Smoluchowskiego 1 Street, Building 4

Shipping: 24h

Stock location: Poland

Delivery: Poland and EU countries

FAQ - CORTECO 12013927B

What are the dimensions of CORTECO 12013927B?

The exact dimensions are 65x85x10 mm.

What material is CORTECO 12013927B made from?

The specified sealing material is NBR - Nitrile Butadiene Rubber.

What is the design of CORTECO 12013927B?

The exact CORTECO design designation is BASLDRWX67.

Is CORTECO 12013927B a wheel hub oil seal?

Yes. Current catalogue data classify reference 12013927B as a wheel hub shaft seal.

Does CORTECO 12013927B have a dust lip?

Yes. The seal incorporates an additional dust lip.

What is the Swirl Type of CORTECO 12013927B?

The specified Swirl Type is Alternating Twist.

Is CORTECO 12013927B suitable for the front axle?

Catalogue data list Front Axle as a fitting position for this reference in applicable vehicles.

Is CORTECO 12013927B suitable for the rear axle?

Yes. Rear Axle is also listed as a fitting position. The exact position depends on the specific vehicle application.

What is the Trade Number for CORTECO 12013927B?

The Trade Number is 82013927.

What is the EAN for CORTECO 12013927B?

The EAN is 3358960340627.

Does CORTECO 12013927B correspond to Renault Trucks 5010216174?

Yes. Renault Trucks 5010216174 is a confirmed OE cross-reference.

Does CORTECO 12013927B correspond to VW 291501317?

Yes. Volkswagen 291501317 is a catalogue OE cross-reference for this seal.

Frequently Asked Questions by Engineers

Are CORTECO 12013927 and 12013927B the same reference?

12013927 is the base reference, while 12013927B is the full CORTECO product reference.

Is BASLDRWX67 the exact design for CORTECO 12013927B?

Yes. Exact-product catalogue data associate BASLDRWX67 with CORTECO 12013927B, dimensions 65x85x10 mm and NBR material.

Is CORTECO 12013927B a double-lip oil seal?

Catalogue data explicitly confirm an additional dust lip. This means the seal has the primary sealing lip plus an auxiliary dust lip.

Is CORTECO 12013927B bidirectional?

The catalogue specification is Alternating Twist. This should be retained as the precise technical term rather than reducing the specification simply to "bidirectional".

Can any 65x85x10 oil seal replace CORTECO 12013927B?

No replacement should be selected solely by dimensions. The NBR material, BASLDRWX67 design, dust lip, Alternating Twist geometry and relevant OE reference should also be verified.

Can CORTECO 01019923B replace CORTECO 12013927B?

Interchangeability should not be assumed. Although both references measure 65x85x10 mm, their materials, designs, directional geometries and catalogue applications differ.

Why is BASLDRWX67 important?

BASLDRWX67 identifies the specific CORTECO sealing construction. It provides more precise technical identification than the nominal dimensions alone.

What are the key identifiers for CORTECO 12013927B?

The key identifiers are 12013927B, 12013927, 82013927, BASLDRWX67, 65x85x10 mm, NBR and EAN 3358960340627, together with the relevant vehicle OE reference.
