CORTECO 12011159 NBR BASL 40x62x7 mm - Radial Shaft Oil Seal with Dust Lip

CORTECO 12011159 NBR BASL 40x62x7 mm - Radial Shaft Oil Seal with Dust Lip

CORTECO 12011159 NBR BASL 40x62x7 mm is a radial shaft oil seal manufactured from nitrile butadiene rubber (NBR), featuring a primary sealing lip and an additional dust protection lip. The seal has a nominal inside diameter of 40 mm, outside diameter of 62 mm and width of 7 mm. Its primary function is to retain lubricants within mechanical assemblies while helping prevent external contaminants from entering the sealing area. The product is identified by CORTECO part number 12011159, with 82011159 provided as an additional reference number. The supplied cross-reference list includes CARRARO, CASE IH, DANA, FENDT, GOLDONI and NEW HOLLAND.

Technical Specifications - CORTECO 12011159

The dimensions listed above are nominal.

Exact dimensional tolerances, operating temperature range, permissible shaft speed and operating pressure must be verified against the manufacturer's technical documentation for part number 12011159.

What Does CORTECO 12011159 NBR BASL 40x62x7 Mean?

The complete designation identifies the manufacturer, construction type, material and nominal dimensions.

• CORTECO - manufacturer brand associated with industrial sealing products and automotive components.

• 12011159 - manufacturer part number.

• 82011159 - additional reference number provided for the product.

• NBR - nitrile butadiene rubber, the elastomer used for the sealing lips.

• BASL - radial shaft seal design featuring an additional dust protection lip.

• 40 - nominal shaft diameter of 40 mm.

• 62 - nominal housing bore diameter of 62 mm.

• 7 - nominal axial width of 7 mm.

The dimensions 40x62x7 mm refer respectively to the inside diameter, outside diameter and width of the oil seal.

BASL Design - Primary Sealing Lip and Additional Dust Lip

The CORTECO 12011159 features a BASL-type construction used in radial shaft sealing applications.

Primary Sealing Lip

The primary sealing lip contacts the rotating shaft surface and creates a sealing interface designed to reduce lubricant leakage from the mechanical assembly.

Its effectiveness depends on appropriate lip contact pressure, shaft surface quality, lubrication and operating conditions.

Additional Dust Protection Lip

The additional dust lip is positioned toward the external side of the sealing arrangement.

Its function is to help prevent dust, dirt and other contaminants from reaching the primary sealing lip.

This design can be particularly useful in mechanical assemblies exposed to contamination during operation.

However, the presence of a dust lip does not automatically mean the seal is suitable for every dusty environment or for submerged operation.

Seal Body Construction

The BASL design combines elastomeric sealing components with structural elements that provide appropriate installation and retention within the housing.

Exact construction details, including the spring specification, reinforcement materials and internal geometry, should be confirmed using the manufacturer's documentation for this specific part number.

NBR Material - Properties of Nitrile Butadiene Rubber

NBR is one of the most widely used elastomers in industrial rotary shaft seals.

Resistance to Oils and Lubricants

NBR is commonly used in contact with many mineral oils and industrial lubricants.

For this reason, nitrile rubber shaft seals are frequently selected for mechanical assemblies requiring lubricant retention.

However, exact compatibility depends on:

• Type of oil or grease.

• Chemical additives.

• Operating temperature.

• Exposure duration.

• Formulation of the specific NBR compound.

Mechanical Resistance

NBR offers mechanical properties suitable for many rotary shaft sealing applications.

Seal durability also depends on shaft surface roughness, shaft hardness, lubrication and correct installation.

Operating Temperature Range

NBR can be used within a temperature range determined by its specific compound formulation.

Exact minimum and maximum operating temperatures should not be assigned to CORTECO 12011159 without confirmation from the manufacturer's technical documentation.

Chemical Limitations

NBR is not resistant to every chemical substance.

Before using the seal with fuels, solvents, aggressive chemicals or unusual operating fluids, material compatibility must be verified.

CORTECO 12011159 - OEM and Cross-Reference Numbers

The following table contains the reference numbers supplied for CORTECO 12011159.

These reference numbers are intended to assist with identification and comparison of replacement parts.

Important: This table reproduces the supplied cross-reference information. It does not constitute independently verified confirmation of compatibility with every machine manufactured by these brands. Before ordering, verify the original part number, machine model, production year, serial number and seal dimensions.

CARRARO 025189

CARRARO 025189 is listed as a cross-reference number for CORTECO 12011159.

When selecting a replacement seal for a CARRARO assembly, verify the original part designation and installation specifications.

CASE IH 87490543

Part number 87490543 is included in the CASE IH reference list.

Compatibility must be confirmed against the parts catalog for the specific machine model.

DANA 000051718

DANA 000051718 is provided as a comparative reference.

When repairing a mechanical assembly, verify whether a BASL-type seal measuring 40x62x7 mm is required.

FENDT X553982600000

FENDT X553982600000 is listed as a reference number for this product.

Correct selection should be confirmed using the machine's technical documentation or original seal identification.

GOLDONI 06220114

GOLDONI 06220114 appears in the supplied reference list.

Dimensional and construction compatibility must be verified before installation.

NEW HOLLAND 87490543

NEW HOLLAND 87490543 is the same reference number listed for CASE IH.

A shared reference number does not automatically establish compatibility with every machine model from either manufacturer.

Typical Applications of 40x62x7 NBR BASL Shaft Seals

Radial shaft seals with dimensions of 40x62x7 mm and BASL construction may be used in appropriately designed mechanical assemblies.

Potential applications include:

• Mechanical gearboxes.

• Drive assemblies.

• Rotating shaft housings.

• Agricultural machinery mechanisms.

• Industrial machine components.

• Systems requiring oil or lubricant retention.

• Mechanical assemblies requiring additional dust protection.

These are general examples of applications for this type of rotary shaft seal.

They do not confirm that CORTECO 12011159 fits a particular gearbox, axle, engine or machine model.

How to Select a Replacement for CORTECO 12011159

When selecting a replacement shaft seal, more than the nominal dimensions must be considered.

The most important parameters include:

1. CORTECO part number 12011159 or a verified original equipment reference.

2. Shaft diameter of 40 mm.

3. Housing bore diameter of 62 mm.

4. Seal width of 7 mm.

5. BASL construction with an additional dust lip.

6. NBR elastomer material.

7. Type and properties of the sealed medium.

8. Operating temperature, rotational speed and pressure.

9. Shaft rotation direction, if the original seal incorporates directional features.

10. Condition of the shaft surface and housing bore.

Can a 40x62x7 BASL Seal Be Replaced with a BA-Type Seal?

Interchangeability should not be assumed.

A BASL-type seal includes an additional dust protection lip that may not be present in a standard BA-type design.

Removing the dust lip may reduce protection against contamination under certain operating conditions.

Can a 40x62x8 Seal Replace a 40x62x7 Seal?

Not automatically.

The difference in axial width is 1 mm and may affect the sealing lip position on the shaft and correct installation within the housing.

Before changing the seal width, verify the housing depth and geometry of the entire assembly.

Can an NBR Shaft Seal Be Replaced with an FKM Seal?

This may be possible in certain applications, but it requires verification of construction, dimensions, material compatibility and operating conditions.

The use of FKM alone does not guarantee that a replacement seal will be suitable for the specific equipment.

Installation of CORTECO 12011159

Correct installation is essential for reliable radial shaft sealing and service life.

Preparing the Shaft and Housing

Before installation:

• Clean the shaft surface.

• Check the shaft for scratches, grooves and corrosion.

• Inspect the housing bore.

• Remove contaminants and burrs.

• Confirm the required dimensions of 40x62x7 mm.

Correct Seal Installation

The oil seal should be pressed evenly into the housing using an appropriate installation tool that does not deform the seal body.

The primary sealing lip should face the correct direction according to the assembly design, normally toward the lubricant being retained.

Before operation, ensure appropriate lubrication of the sealing lip contact area in accordance with the manufacturer's recommendations.

Common Installation Mistakes

• Installing the seal at an angle.

• Damaging the sealing lip on sharp shaft edges.

• Using an incorrect seal size.

• Installing the seal on a worn shaft surface.

• Incorrect orientation of the primary sealing lip.

• Insufficient initial lubrication.

• Applying excessive installation force.

Alternative Product Names and Commercial Designations

The product may be searched for under the following names:

• CORTECO 12011159

• CORTECO 82011159

• CORTECO Oil Seal 40x62x7

• CORTECO 12011159 Simmerring

• Simmerring 40x62x7 NBR BASL

• NBR Shaft Seal 40x62x7 mm

• Rotary Shaft Seal 40x62x7 with Dust Lip

• CORTECO Radial Shaft Seal 12011159

• CARRARO 025189 Oil Seal

• CASE IH 87490543 Shaft Seal

• DANA 000051718 Oil Seal

• FENDT X553982600000 Shaft Seal

• GOLDONI 06220114 Oil Seal

• NEW HOLLAND 87490543 Shaft Seal

• CORTECO 12011159 Radial Shaft Seal

• CORTECO 40x62x7 Oil Seal

• Radialwellendichtring 40x62x7 BASL

• 40x62x7 NBR Rotary Shaft Oil Seal

• 40x62x7 Уплотнительное кольцо с пылезащитной кромкой

Frequently Asked Questions - CORTECO 12011159

1. What are the dimensions of CORTECO 12011159?

The seal has a nominal inside diameter of 40 mm, outside diameter of 62 mm and axial width of 7 mm.

2. What does BASL mean in a CORTECO shaft seal?

BASL identifies a radial shaft seal design featuring an additional dust protection lip.

3. What material is CORTECO 12011159 made from?

The elastomeric sealing components are made from nitrile butadiene rubber (NBR).

4. Does CORTECO 12011159 have an additional dust lip?

Yes. The BASL designation indicates an additional lip designed to help prevent contaminants from reaching the primary sealing area.

5. Is CORTECO 12011159 compatible with CASE IH 87490543?

Part number 87490543 is provided as a cross-reference. Final compatibility must be confirmed using the parts catalog for the specific CASE IH machine model.

6. Does CORTECO 12011159 correspond to NEW HOLLAND 87490543?

Reference number 87490543 appears in the supplied NEW HOLLAND cross-reference list. Compatibility with a particular machine must be verified before installation.

7. Can CORTECO 12011159 be used in a gearbox?

NBR BASL radial shaft seals are used in suitable gearbox assemblies. Whether this particular seal is appropriate depends on the assembly design, sealed medium and operating conditions.

8. Can a 40x62x7 BASL seal be replaced with a standard 40x62x7 oil seal?

Not always. Construction type, material, dust lip configuration and other technical parameters must be checked.

9. Is NBR resistant to gearbox oil?

NBR is commonly used with many mineral oils. However, compatibility with a particular gearbox oil and its additives must be verified.

10. Which OEM reference numbers are associated with CORTECO 12011159?

The supplied cross-reference list includes CARRARO 025189, CASE IH 87490543, DANA 000051718, FENDT X553982600000, GOLDONI 06220114 and NEW HOLLAND 87490543. These references require verification for the specific application.

11. Are CORTECO 12011159 and 82011159 the same product?

82011159 has been provided as an additional reference for product 12011159. The relationship between these numbers should be confirmed in the manufacturer's current catalog before treating them as fully interchangeable identifiers.

12. Is CORTECO 12011159 designed for rotating shafts?

Yes. It is a radial shaft seal whose primary sealing lip operates against the surface of a rotating shaft.

CORTECO 12011159 40x62x7 NBR BASL - Key Product Information

CORTECO 12011159 is a BASL-type radial shaft oil seal measuring 40x62x7 mm, manufactured from nitrile butadiene rubber (NBR) and featuring an additional dust protection lip. It is designed to retain lubricants and help protect the sealing area against external contamination. The additional reference number supplied is 82011159. The cross-reference list includes CARRARO, CASE IH, DANA, FENDT, GOLDONI and NEW HOLLAND.
