SKF 6005 2RS 25x47x12 mm is a single-row deep groove ball bearing with contact seals on both sides. Designed to accommodate radial loads and moderate axial loads in both directions, it features a compact construction and factory grease lubrication. The commercial designation 2RS does not uniquely identify the SKF seal variant; specific versions such as 2RSH or 2RS1 require confirmation. Available through simmering.pl, a specialist B2B industrial supply platform, with worldwide shipping from stock in Poland.
|
Parameter |
Specification |
|---|---|
|
Manufacturer |
SKF |
|
Commercial designation |
6005 2RS |
|
Bearing type |
Deep groove ball bearing |
|
Design |
Single-row |
|
Bearing series |
6005 |
|
Dimensions |
25x47x12 mm |
|
Bore diameter (d) |
25 mm |
|
Outside diameter (D) |
47 mm |
|
Width (B) |
12 mm |
|
Sealing arrangement |
Contact seals on both sides, indicated by 2RS |
|
Rolling elements |
Balls |
|
Load direction |
Radial and axial in both directions |
|
Internal clearance |
To be confirmed for the exact SKF designation |
|
Cage type |
To be confirmed for the exact SKF designation |
|
Lubrication |
Factory grease-filled sealed design |
|
Basic dynamic load rating |
To be confirmed for the exact variant |
|
Basic static load rating |
To be confirmed for the exact variant |
|
Limiting speed |
To be confirmed for the exact variant |
|
Mass |
To be confirmed |
Product identification: The designation 6005 2RS alone does not uniquely identify the complete SKF catalogue variant. Parameters dependent on the specific design must be verified against the bearing markings or the manufacturer's documentation.
The bearing consists of an inner ring, an outer ring, one row of steel balls and a cage that maintains the spacing between the rolling elements.
Its deep groove raceway geometry allows the bearing to accommodate radial loads and axial loads acting in either direction.
The single-row design provides a compact axial width while supporting combined loading within the operating limits of the bearing.
The principal components include:
Inner ring with a deep groove raceway.
Outer ring with a corresponding raceway.
One row of rolling elements.
Ball-guiding cage.
Two contact seals.
Factory-applied grease lubrication.
The exact cage material and seal construction should be confirmed for the complete SKF product designation.
The designation 2RS is commonly used in industrial bearing identification to describe bearings fitted with elastomeric contact seals on both sides.
Their primary functions include:
Limiting the ingress of dust and contaminants.
Helping retain lubricant inside the bearing.
Protecting the rolling elements and raceways.
Reducing exposure of the internal bearing components to the environment.
SKF uses specific suffixes, including 2RSH and 2RS1, to identify different contact seal designs.
These suffixes should not automatically be considered identical.
Contact seals generate friction during operation, which can reduce permissible operating speed compared with a corresponding open bearing.
|
Symbol |
Dimension |
Description |
|---|---|---|
|
d |
25 mm |
Inner ring bore diameter |
|
D |
47 mm |
Outer ring outside diameter |
|
B |
12 mm |
Total bearing width |
The principal dimensions provide the basis for identifying the bearing's geometric size.
However, matching dimensions alone do not establish complete interchangeability.
The sealing arrangement, internal clearance, accuracy class and operating conditions must also be considered.
Deep groove ball bearings of the SKF 6005 series are primarily designed to accommodate radial loads.
Their raceway geometry also enables them to carry axial loads in both directions.
The permissible axial load depends on several factors:
Radial loading.
Operating internal clearance.
Rotational speed.
Lubrication conditions.
Operating temperature.
Shaft and housing arrangement.
Without confirming the exact SKF variant, specific dynamic and static load ratings should not be assigned to this product.
Radial internal clearance influences bearing operation after installation.
Depending on the complete designation, bearings may be manufactured with normal or increased internal clearance.
|
Feature |
Normal clearance CN |
Increased clearance C3 |
|---|---|---|
|
Initial internal clearance |
Normal |
Greater than normal |
|
Effect of interference fits |
May reduce operating clearance |
May reduce operating clearance |
|
Selection |
Application-dependent |
Application-dependent |
|
Interchangeability |
Requires verification |
Requires verification |
The designation SKF 6005 2RS does not independently confirm C3 clearance.
A C3 variant must be identified using the appropriate manufacturer designation.
Deep groove ball bearings with contact seals on both sides are generally factory grease-filled and designed to operate without routine internal relubrication.
Grease service life depends on:
Operating temperature.
Rotational speed.
Applied loads.
Environmental conditions.
Operating duration.
Contact seals do not guarantee complete protection against high-pressure water, immersion or aggressive chemicals.
The precise temperature limits and permissible operating speed must be established for the confirmed SKF variant.
The permissible operating speed of SKF 6005 2RS depends on the specific sealing design and application conditions.
Contact seals generate additional friction compared with non-contact shields or open bearing designs.
Relevant factors include:
Seal friction.
Lubricant characteristics.
Radial and axial loading.
Bearing temperature.
Shaft and housing fits.
Heat dissipation.
A numerical limiting speed should only be specified after confirming the complete SKF catalogue designation.
Single-row sealed deep groove ball bearings measuring 25x47x12 mm may be used in appropriately designed mechanical assemblies, including:
Electric motors.
Industrial fans and blowers.
Pumps and auxiliary equipment.
Material handling mechanisms.
Mechanical drive assemblies.
Industrial machinery with rotating shafts.
These are general applications of this bearing category, not a confirmed equipment compatibility list for a particular SKF 6005 variant.
Before installing SKF 6005 2RS, inspect the shaft, housing and bearing seating surfaces.
Recommended procedures include:
Clean the mounting surfaces.
Verify shaft and housing tolerances.
Remove burrs and sharp edges.
Use suitable bearing installation tools.
Apply mounting force to the ring being fitted.
Never transmit installation force through the rolling elements.
Protect the contact seals from damage.
Check correct seating and smooth rotation after installation.
Incorrect installation may damage the raceways, increase vibration and noise, or reduce bearing service life.
|
Feature |
SKF 6005 2RS |
SKF 6005 2Z |
|---|---|---|
|
Dimensions |
25x47x12 mm |
25x47x12 mm |
|
Bearing type |
Single-row deep groove ball |
Single-row deep groove ball |
|
Closure type |
Contact seals |
Metal shields |
|
Seal contact |
Contact |
Non-contact |
|
Friction |
Generally higher |
Generally lower |
|
Contamination protection |
Depends on seal design |
Depends on operating environment |
|
Permissible speed |
Variant-dependent |
Variant-dependent |
Although both designs share the same nominal principal dimensions, they differ in sealing construction, friction characteristics and operating requirements.
They should not automatically be considered interchangeable.
An open SKF 6005 bearing does not have integrated side seals or shields.
Its contamination protection and lubrication arrangement depend on the surrounding equipment design.
The double-sealed version provides integrated protection and is generally factory grease-filled.
Selection between open and sealed versions should consider operating speed, environmental exposure, lubrication and maintenance requirements.
Incorrect mounting fits: May cause undesirable changes in operating clearance, ring creep or excessive temperature.
Seal damage: May allow lubricant loss and contamination ingress.
Excessive loading: May accelerate rolling contact fatigue.
Misalignment: May cause uneven load distribution and increased internal stress.
High operating temperature: May reduce grease performance and affect sealing materials.
Incorrect installation: May permanently damage the rolling elements or raceways.
SKF 6005 2RS 25x47x12 mm
SKF 6005-2RS
SKF 6005 2RS Deep Groove Ball Bearing
SKF 6005 Double Sealed Ball Bearing
SKF 6005 Rubber Sealed Bearing
SKF 6005 25x47x12 mm Sealed Bearing
SKF 6005-2RSH and SKF 6005-2RS1 are manufacturer-specific variants that require confirmation before being assigned to the product.
These alternative descriptions support identification in industrial catalogues and procurement systems but do not establish interchangeability between different SKF variants.
What are the dimensions of SKF 6005 2RS?
The bearing has a bore diameter of 25 mm, an outside diameter of 47 mm and a width of 12 mm.
What type of bearing is SKF 6005 2RS?
It is a single-row deep groove ball bearing with contact seals on both sides.
What does 2RS mean?
It is a general commercial designation indicating contact seals on both sides. The exact SKF seal variant must be confirmed separately.
Does SKF 6005 2RS have C3 clearance?
The designation alone does not confirm C3 clearance. The appropriate clearance suffix must be verified using the complete manufacturer designation.
Can SKF 6005 2RS accommodate axial loads?
Yes. Deep groove ball bearings can accommodate axial loads in both directions within their permissible operating limits.
Does the bearing require relubrication?
Double-contact-sealed versions are generally factory grease-filled and are not intended for routine internal relubrication.
Are SKF 6005 2RS and SKF 6005 2Z interchangeable?
Not automatically. They differ in sealing design, friction characteristics and operating limitations.
What is the maximum operating speed?
The limiting speed must be confirmed for the exact SKF variant because it depends on the sealing arrangement and operating conditions.
SKF 6005 2RS 25x47x12 mm is a single-row deep groove ball bearing with contact seals on both sides. It accommodates radial loads and moderate axial loads in both directions. The exact SKF seal variant, such as 2RSH or 2RS1, must be verified because the general commercial designation 2RS does not uniquely identify a specific SKF catalogue configuration.
SKF 6005 2RS 25x47x12 mm is offered through simmering.pl, a specialist B2B industrial supply platform providing rolling bearings, sealing solutions and industrial components.
The platform serves manufacturing companies, wholesale buyers, maintenance departments, engineers and industrial procurement teams.
Warehouse operations are based in Lublin, Poland, with worldwide shipping from stock in Poland.
Technical support includes bearing identification, dimensional verification and assistance with selecting suitable bearing configurations.
