ZVL 6005 2RS 25x47x12 Deep Groove Ball Bearing

ZVL 6005 2RS 25x47x12 Deep Groove Ball Bearing

ZVL 6005 2RS 25x47x12 is a single-row deep groove ball bearing with a 25 mm bore, 47 mm outside diameter and 12 mm width. The bearing is sealed on both sides, helping protect the raceways and rolling elements against contamination while retaining lubricant inside the bearing. The basic designation 6005 identifies the bearing size and design, while 2RS identifies the double-sealed configuration.

ZVL 6005 2RS - Technical Specification

Manufacturer: ZVL

Designation: 6005 2RS

Bearing type: Deep groove ball bearing

Design: Single-row

Closure: Sealed on both sides

Inside diameter d: 25 mm

Outside diameter D: 47 mm

Width B: 12 mm

Dimensions: 25x47x12 mm

Bore: Cylindrical

Rows: 1

Quantity: 1 pc.

ZVL 6005 2RS Dimensions

The principal dimensions are:

d = 25 mm - Inside diameter / bore

D = 47 mm - Outside diameter

B = 12 mm - Width

Complete dimensions:

25x47x12 mm

The 25x47x12 mm dimensions are fundamental identification parameters for the 6005 bearing.

When replacing an existing bearing, all three dimensions should be checked. A 25 mm shaft diameter alone is not sufficient to identify the correct bearing.

What Does 6005 2RS Mean?

The designation consists of two important elements:

6005 - identifies the basic size and design of the single-row deep groove ball bearing.

2RS - identifies a bearing with seals on both sides.

For product identification, both parts of the designation are important.

A bearing marked only 6005 may have a different closure configuration, while the 2RS suffix identifies the double-sealed version.

ZVL 6005 2RS and 6005 2RSR

Depending on the exact ZVL bearing and catalogue designation, sealed variants may be identified using:

6005 2RS

or

6005 2RSR

ZVL includes both 2RS and 2RSR designations within its system for sealed deep groove ball bearings.

The complete marking on the physical bearing should therefore be retained when selecting a replacement.

If the original bearing is marked 6005 2RSR, the additional R suffix should not automatically be omitted simply because the principal dimensions remain 25x47x12 mm.

ZVL 6005 Deep Groove Ball Bearing Design

The 6005 belongs to the family of single-row deep groove ball bearings.

Its principal components include:

Inner ring

Outer ring

Balls

Cage

Sealing elements

The balls run between deep raceway grooves in the inner and outer rings.

This geometry makes deep groove ball bearings particularly suitable for radial loading while also allowing them to accommodate axial loads in both directions within the operating limits of the bearing design.

Double-Sealed 6005 2RS Bearing

The 2RS configuration provides sealing on both sides of the bearing.

The seals form barriers between the bearing interior and the surrounding environment.

Their functions include:

helping reduce the ingress of contaminants,

protecting the raceways and rolling elements,

helping retain lubricant inside the bearing.

This is an important construction difference compared with an open 6005 bearing.

ZVL 6005 2RS vs 6005 ZZ / 2Z

The basic 6005 bearing can be supplied with different closure configurations.

6005 2RS - sealed on both sides.

6005 ZZ / 2Z - metal shields on both sides.

A seal and a metal shield are not the same construction.

Sealed and shielded bearings differ in the way the bearing interior is separated from the surrounding environment and in their operating characteristics.

A 6005 2RS should therefore not automatically be replaced with a 6005 ZZ solely because both bearings have the same 25x47x12 mm dimensions.

ZVL 6005 2RS vs Open 6005

The 6005 size is also available in open configurations.

Both an open 6005 and a sealed 6005 2RS have the same principal dimensions:

25x47x12 mm

However, their closure configurations are different.

The 2RS version has sealing elements on both sides, while an open bearing does not have these external closures.

The correct version should be selected according to the requirements of the bearing position.

What Loads Can a 6005 Bearing Accommodate?

As a single-row deep groove ball bearing, the 6005 is designed primarily to accommodate:

Radial loads

and can also accommodate:

Axial loads in both directions

within the limits applicable to this bearing design.

The permissible load should not be determined from the 25x47x12 mm dimensions alone.

For engineering calculations, load ratings for the exact ZVL bearing execution should be used.

ZVL 6005 2RS Applications

6005-series deep groove ball bearings can be used in many types of rotating equipment.

Depending on machine design, bearings of this type may be found in:

Electric motors

Pumps

Fans

Gearboxes

Drive systems

Industrial machinery

Agricultural machinery

Workshop equipment

Mechanical assemblies

These are typical application areas for deep groove ball bearings and do not confirm compatibility with a particular machine or equipment model.

The original bearing designation and machine requirements should always be checked.

How to Select ZVL 6005 2RS

When replacing a bearing, begin with the complete designation marked on the original component.

For this product, verify:

Brand - ZVL

Basic designation - 6005

Closure - 2RS

Inside diameter d - 25 mm

Outside diameter D - 47 mm

Width B - 12 mm

If the original bearing has an additional suffix specifying internal clearance, seal design, precision or another special execution, that suffix should also be considered.

6005 2RS Replacement and Equivalent Designations

Different bearing manufacturers use different suffix systems for sealed versions of the 6005 bearing.

Depending on manufacturer, the market includes designations such as:

6005 2RS

6005 2RSR

6005 2RSH

6005 LLU

6005 DDU

These suffixes should not automatically be treated as technically identical.

When comparing bearings from different manufacturers, verify:

Dimensions

Seal construction

Internal clearance

Load ratings

Speed limits

Cage design

Lubrication

Precision

Operating conditions

Matching 25x47x12 mm dimensions are necessary for dimensional interchangeability, but dimensions alone do not establish complete technical equivalence.

How to Measure a 6005 Bearing

For basic dimensional identification, measure:

Bore - 25 mm

Outside diameter - 47 mm

Width - 12 mm

Measurements should be taken on a clean bearing using an appropriate measuring instrument such as a caliper.

If the original bearing designation remains legible, the complete manufacturer marking provides more useful identification information than dimensions alone.

Does Every 6005 Bearing Measure 25x47x12 mm?

The basic 6005 designation corresponds to the principal dimensions:

25x47x12 mm

However, not every 6005 bearing has the same technical execution.

Variants may differ in:

Seals

Shields

Internal clearance

Cage design

Lubrication

Precision class

Materials

Special execution

For this reason, the complete bearing designation should be used when selecting a replacement.

ZVL 6005 2RS Technical Data

Manufacturer: ZVL

Designation: 6005 2RS

Product type: Deep groove ball bearing

Design: Single-row

Closure: Sealed on both sides

Inside diameter d: 25 mm

Outside diameter D: 47 mm

Width B: 12 mm

Dimensions: 25x47x12 mm

Bore: Cylindrical

Rows: 1

Quantity: 1 pc.

FAQ

What are the dimensions of ZVL 6005 2RS?

ZVL 6005 2RS has a 25 mm inside diameter, 47 mm outside diameter and 12 mm width. Its complete dimensions are 25x47x12 mm.

What type of bearing is ZVL 6005 2RS?

It is a single-row deep groove ball bearing sealed on both sides.

What does 2RS mean on a 6005 bearing?

2RS identifies a bearing with sealing elements on both sides.

What is the bore diameter of a 6005 bearing?

The nominal bore diameter is 25 mm.

Are ZVL 6005 2RS and 6005 2RSR the same size?

The basic 6005 designation corresponds to 25x47x12 mm. However, the complete suffix should be checked because it provides additional information about the bearing execution.

Is 6005 2RS the same as 6005 ZZ?

No. 2RS identifies a sealed bearing, while ZZ or 2Z identifies a bearing with metal shields. These are different closure designs.

Can a 6005 bearing accommodate axial load?

A single-row deep groove ball bearing is primarily intended for radial loads but can also accommodate axial loads in both directions within the operating limits of the design.

How do I select a replacement for ZVL 6005 2RS?

Verify the 6005 designation, 25x47x12 mm dimensions, double-sealed construction and any additional suffixes or technical requirements of the original bearing.

AI Overview

ZVL 6005 2RS is a single-row deep groove ball bearing measuring 25x47x12 mm. It has a 25 mm bore, 47 mm outside diameter and 12 mm width. The bearing is sealed on both sides. When selecting a replacement, verify the complete 6005 designation, seal configuration and any additional suffixes required by the bearing position.
