6202 2RS C4 FAG Deep Groove Ball Bearing - 15x35x11 mm, Double Rubber Sealed

6202 2RS C4 FAG Deep Groove Ball Bearing - 15x35x11 mm, Double Rubber Sealed

The 6202 2RS C4 FAG Deep Groove Ball Bearing is a premium-quality bearing designed for high-speed and high-load applications. Manufactured by FAG, a renowned leader in bearing technology, this bearing features double rubber seals (denoted by "2RS") to protect against contamination and retain lubrication, ensuring longevity and reliable performance.

Technical Specifications:

• Inner Diameter (ID): 15 mm

• Outer Diameter (OD): 35 mm

• Width (B): 11 mm

• Seal Type: 2RS (Double Rubber Seals)

• Material: High-grade bearing steel

• Cage Material: Steel

• Radial Clearance: C4 (Increased clearance for high-speed applications)

• Dynamic Load Rating: 8.2 kN

• Static Load Rating: 3.75 kN

• Limiting Speed: Up to 12,700 RPM

• Operating Temperature Range: -30°C to +110°C

• Weight: Approximately 0.04 kg

Key Features and Benefits:

• Durable Construction: Made from high-quality bearing steel for enhanced strength and durability.

• Double Rubber Seals (2RS): Provides superior protection against dust and debris while retaining lubricant.

• High-Speed Capability: Suitable for applications requiring high rotational speeds.

• Versatile Use: Ideal for both radial and axial loads in various directions.

• Maintenance-Free: Pre-lubricated for life, reducing the need for maintenance.

Typical Applications:

• Electric motors

• Automotive transmissions

• Industrial machinery

• Agricultural equipment

• HVAC systems

• Power tools

Frequently Asked Questions (FAQ)

Q1: What does "2RS" signify in this bearing?
"2RS" indicates that the bearing has rubber seals on both sides, providing protection against contamination and retaining lubrication.

Q2: Is this bearing suitable for high-speed applications?
Yes, the 6202 2RS C4 FAG bearing is designed to operate efficiently at high speeds, with a limiting speed of up to 12,700 RPM.

Q3: Can this bearing handle axial loads?
Absolutely. While primarily designed for radial loads, it can also accommodate axial loads in both directions.

Q4: Is additional lubrication required?
No, this bearing is pre-lubricated for life and does not require additional lubrication under normal operating conditions.
