SKF 6202-2RS1 15x35x11 Deep Groove Ball Bearing

SKF 6202-2RS1 is a single-row deep groove ball bearing measuring 15x35x11 mm. It has a 15 mm bore diameter, 35 mm outside diameter and 11 mm width. The 2RS1 suffix identifies the sealed configuration with seals on both sides, distinguishing this version from open 6202 and shielded 6202-2Z variants.

SKF 6202-2RS1 - Product Characteristics

SKF 6202-2RS1 belongs to the 62 series of single-row deep groove ball bearings.

Verified principal data for the 6202 size are:

Manufacturer / Brand: SKF
Designation: 6202-2RS1
Bearing Type: Single-row deep groove ball bearing
Dimensions: 15x35x11 mm
Basic Dynamic Load Rating C: 8.06 kN
Basic Static Load Rating C0: 3.75 kN
Fatigue Load Limit Pu: 0.16 kN

The complete suffix should be preserved during identification because different 6202 variants can have the same principal dimensions but different closure arrangements.

Dimensions

The principal dimensions of SKF 6202-2RS1 are:

d - Bore Diameter: 15 mm
D - Outside Diameter: 35 mm
B - Width: 11 mm
Commercial Size: 15x35x11 mm

For this bearing, the commercial dimensional notation 15x35x11 mm corresponds directly to d x D x B.

Bearing Construction

SKF 6202-2RS1 is a single-row deep groove ball bearing.

The rolling elements are balls running between deep raceway grooves in the inner and outer rings. This geometry is designed primarily for radial loading but also enables the bearing to accommodate axial loads in both directions.

The construction should therefore be distinguished from bearing types intended mainly for one-direction axial loading or from bearings with different raceway geometries.

2RS1 Sealing

The suffix 2RS1 identifies the sealed version of the bearing.

The bearing is equipped with seals on both sides. These seals help retain lubricant inside the bearing and reduce the ingress of contaminants into the rolling contact area.

Within the same 6202 dimensional size, SKF also offers other closure configurations, including:

6202 - open version
6202-2RS1 - sealed on both sides
6202-2Z - shielded on both sides

These versions share the same basic 15x35x11 mm dimensions but should not automatically be treated as technically identical.

Load Ratings and Operating Principle

SKF catalogue data for the 6202 size specify:

C - Basic Dynamic Load Rating: 8.06 kN
C0 - Basic Static Load Rating: 3.75 kN
Pu - Fatigue Load Limit: 0.16 kN

The deep groove design allows the bearing to carry primarily radial loads and also axial loads acting in both directions.

The values C and C0 are catalogue load ratings, not simple maximum permissible machine loads. Actual bearing selection should consider load magnitude and direction, speed, required service life, shaft and housing fits, lubrication, temperature and operating conditions.

Meaning of 6202-2RS1

The complete designation provides technical identification of the bearing.

6 - single-row deep groove ball bearing family

62 - dimensional series

02 - bore code corresponding to a 15 mm bore diameter

2RS1 - sealed configuration with seals on both sides

In commercial use, the shorter expression 6202 2RS is common, but when the exact SKF designation is known, 6202-2RS1 should be retained on the technical product page.

SKF 6202-2RS1 vs 6202

Both versions have the same principal dimensions of 15x35x11 mm.

The difference is the closure arrangement:

SKF 6202 is open.

SKF 6202-2RS1 is sealed on both sides.

This difference affects the bearing configuration and should be considered during replacement selection.

SKF 6202-2RS1 vs 6202-2Z

Both bearings measure 15x35x11 mm, but they use different closure systems.

6202-2RS1 uses seals.

6202-2Z uses metal shields.

The same d, D and B dimensions therefore do not prove complete technical interchangeability.

Selection and Interchangeability

When selecting a replacement for SKF 6202-2RS1, compare at least:

• bearing type,
• d = 15 mm,
• D = 35 mm,
• B = 11 mm,
• closure arrangement,
• radial internal clearance,
• accuracy class where specified,
• dynamic load rating,
• static load rating,
• speed requirements,
• lubrication and operating conditions.

Particular attention should be paid to additional suffixes such as C3. A 6202-2RS1/C3 bearing has a different internal-clearance specification and should not automatically be treated as identical to the standard version.

Technical Specification

Manufacturer / Brand: SKF
Designation: 6202-2RS1
Product Type: Deep groove ball bearing
Construction: Single row
Dimensions: 15x35x11 mm
d - Bore Diameter: 15 mm
D - Outside Diameter: 35 mm
B - Width: 11 mm
Closure: Seals on both sides
Basic Dynamic Load Rating C: 8.06 kN
Basic Static Load Rating C0: 3.75 kN
Fatigue Load Limit Pu: 0.16 kN
Axial Load Capability: Both directions

FAQ

What are the dimensions of SKF 6202-2RS1?

SKF 6202-2RS1 measures 15x35x11 mm: 15 mm bore diameter, 35 mm outside diameter and 11 mm width.

What type of bearing is SKF 6202-2RS1?

It is a single-row deep groove ball bearing.

What does 2RS1 mean?

The 2RS1 suffix identifies the version with seals on both sides.

What is the load rating of SKF 6202?

SKF catalogue data for the 6202 size specify C = 8.06 kN, C0 = 3.75 kN and Pu = 0.16 kN.

Can SKF 6202-2RS1 carry axial loads?

Yes. Its deep groove construction allows it to carry axial loads in both directions in addition to radial loads.

Is 6202-2RS1 the same as 6202-2Z?

No. They have the same 15x35x11 mm dimensions, but 2RS1 uses seals while 2Z uses shields.

Is 6202-2RS1/C3 the same as 6202-2RS1?

No. The C3 suffix identifies increased radial internal clearance, so the required clearance must be checked for the specific bearing arrangement.

Can another 15x35x11 bearing replace SKF 6202-2RS1?

Not automatically. Dimensions alone are not enough. The bearing type, sealing arrangement, internal clearance, load ratings, speed capability and operating conditions should also be compared.
