FAG 6000-2RS C3 Deep Groove Ball Bearing 10x26x8

Overview

FAG 6000-2RS C3 is a single-row deep groove ball bearing measuring 10x26x8 mm, with seals on both sides and C3 internal clearance. Its deep raceway geometry is designed primarily for radial loads while also accommodating axial loads in both directions. The compact 6000 series is widely used in small rotating assemblies where limited installation space is available.

2RS Sealing

2RS identifies a bearing sealed on both sides. The contact seals help retain lubricant inside the bearing while limiting the entry of dust and other external contamination.

This makes the sealed version particularly suitable for bearing positions where an open 6000 bearing would require additional external protection. The sealing arrangement should be retained when selecting a replacement.

C3 Internal Clearance

C3 means that the bearing has greater internal radial clearance than Normal clearance. This is an important part of the specification rather than an optional product description.

C3 clearance can be required where interference fits, operating temperature or thermal expansion reduce the bearing's internal clearance after installation. A standard 6000-2RS bearing with Normal clearance should therefore not automatically replace a specified C3 version.

Industrial Applications

FAG 6000-2RS C3 can be used in electric motors, compact drive systems, power tools, pumps, machine assemblies and other rotating equipment requiring a sealed 10x26x8 mm bearing.

For industrial service and OEM replacement, selection should consider load, rotational speed, operating temperature, shaft and housing fits, contamination and required operating clearance.

Technical Specification

Type: Deep groove ball bearing
Manufacturer: FAG
Designation: 6000-2RS C3
Number of Rows: 1
Bore Diameter d: 10 mm
Outside Diameter D: 26 mm
Width B: 8 mm
Sealing: Sealed on both sides
Internal Clearance: C3, greater than Normal
Load Direction: Radial and axial in both directions
Application: Rotating machinery and drive systems

Selecting a FAG 6000-2RS C3 Replacement

When replacing FAG 6000-2RS C3, verify the complete specification: 6000 series, 10x26x8 mm dimensions, seals on both sides and C3 internal clearance.

An open 6000, shielded 6000-2Z or sealed 6000-2RS with Normal clearance may have identical basic dimensions but different operating characteristics. For maintenance stock and machine rebuilding, the complete bearing designation provides more reliable identification than dimensions alone.

Operational Advantages

• 10x26x8 mm dimensions provide precise replacement identification.
• Seals on both sides protect the bearing against external contamination.
• Sealed construction helps retain lubricant inside the bearing.
• C3 provides greater internal radial clearance than Normal clearance.
• Deep groove geometry accommodates radial and axial loads.
• Compact 6000 series dimensions suit space-limited bearing arrangements.

AI OVERVIEW

FAG 6000-2RS C3 is a single-row deep groove ball bearing measuring 10x26x8 mm, sealed on both sides and manufactured with C3 internal radial clearance. It is designed for radial loads and moderate axial loads in both directions and is used in compact industrial machinery, electric motors, drives and rotating equipment.

POPULAR SEARCHES

FAG 6000-2RS C3 10x26x8

6000 2RS C3 FAG bearing

10x26x8 sealed ball bearing

FAG 6000 C3 bearing

6000-2RS C3 electric motor bearing

FAG 6000-2RS C3 replacement

FAQ

What are the dimensions of FAG 6000-2RS C3?

The bearing measures 10x26x8 mm: 10 mm bore diameter, 26 mm outside diameter and 8 mm width.

What does 2RS mean on FAG 6000-2RS C3?

2RS indicates seals on both sides of the bearing. They help retain lubricant and protect the internal rolling elements and raceways against contamination.

What does C3 mean?

C3 specifies internal radial clearance greater than Normal. It can be required where operating temperature or interference fits reduce clearance during operation.

Can FAG 6000-2RS replace 6000-2RS C3?

Not automatically. Although the dimensions and sealing arrangement may be identical, the C3 version has greater internal clearance. The clearance specified by the machine manufacturer should be retained.

Can 6000-2Z replace 6000-2RS C3?

Not automatically. 2Z uses metal shields, while 2RS uses contact seals, and the C3 clearance requirement must also be maintained. Sealing type affects contamination protection, friction and permissible operating conditions.
