FAG 6200-2RSR-C3 10x30x9 - Deep Groove Ball Bearing

6200-2RSR-C3 FAG 10x30x9 mm - Deep Groove Ball Bearing

6200-2RSR-C3 FAG is a single-row deep groove ball bearing manufactured by FAG, a brand of Schaeffler, with dimensions of 10x30x9 mm. It has a 10 mm bore diameter, a 30 mm outside diameter and a 9 mm width. The bearing belongs to the 62 series and features contact seals on both sides, designated 2RSR, together with C3 radial internal clearance greater than normal. It is factory lubricated and designed to accommodate radial and appropriate axial loads.

Technical Specifications - 6200-2RSR-C3 FAG

Load ratings and speed limits for this designation may differ from those of newer Generation C variants. Therefore, technical values for 6200-C-2HRS-C3 must not automatically be assigned to the earlier 6200-2RSR-C3 version.

What Does 6200-2RSR-C3 FAG Mean?

6200 - Bearing Series and Size

The designation 6200 identifies a single-row deep groove ball bearing from the 62 dimensional series.

The designation consists of:

• 6 - deep groove ball bearing.

• 2 - dimensional series 62.

• 00 - bore diameter code corresponding to 10 mm.

The bearing has standard dimensions of 10x30x9 mm.

Its deep groove construction enables it to accommodate primarily radial loads and appropriate axial loads in both directions.

2RSR - Contact Seals on Both Sides

The FAG suffix 2RSR indicates contact seals installed on both sides of the bearing.

The seals contact the inner ring and separate the rolling element space from the surrounding environment.

Their main functions include:

• Reducing the entry of dust and contaminants.

• Retaining grease inside the bearing.

• Protecting the balls and raceways.

• Limiting moisture ingress under suitable conditions.

• Reducing the need for external lubrication maintenance.

Contact seals generate additional friction compared with open bearings or bearings fitted with metal shields.

They do not provide complete waterproofing.

C3 - Greater Than Normal Radial Internal Clearance

The C3 suffix indicates radial internal clearance greater than normal.

C3 clearance may be required in applications where:

• Interference fits are used.

• The inner ring operates at a higher temperature than the outer ring.

• Differences in thermal expansion occur.

• Mounting conditions reduce operating internal clearance.

C3 does not automatically indicate increased load capacity, a higher precision class or a higher permissible rotational speed.

The appropriate internal clearance must be selected according to mounting and operating conditions.

Alternative Designations and Reference Numbers

The product may be searched for using the following variations:

• 6200-2RSR-C3 FAG

• FAG 6200-2RSR-C3

• 6200 2RSR C3 FAG

• FAG 6200 2RS C3

• 6200 2RS C3 FAG

• 6200-2RS-C3 FAG

• FAG 6200 2RS 10x30x9 C3

The FAG 6200-C-2HRS-C3 variant is also available in the market.

These designations identify different bearing designs. They must not be considered identical without checking the technical specifications and application requirements.

Construction of 6200-2RSR-C3 FAG

Inner Ring - 10 mm Bore

The inner ring has a bore diameter of 10 mm.

It operates with a shaft having an appropriately selected mounting tolerance.

Excessive interference may reduce operating internal clearance beyond the intended range.

Outer Ring - 30 mm Outside Diameter

The outer ring has an outside diameter of 30 mm.

It is designed for installation in a housing providing adequate support and a suitable fit.

Bearing Width - 9 mm

The bearing width is 9 mm.

This dimension must be considered when selecting spacers, axial shoulders and locating components.

Balls and Raceways

The bearing contains a single row of balls running between deep raceways in the inner and outer rings.

This construction enables it to support radial loads and appropriate axial loads in both directions.

Steel Cage

The cage maintains the correct spacing between the balls and reduces direct contact between adjacent rolling elements.

2RSR Contact Seals

Two contact seals protect the rolling element space.

Their condition is important for grease retention and contamination protection.

Load Ratings and Operating Conditions

Basic Dynamic Load Rating

The basic dynamic load rating C is used to calculate the nominal fatigue life of the bearing.

It does not represent the maximum permissible operating force.

For FAG 6200-2RSR-C3, the value must correspond to the specific bearing design and generation.

Basic Static Load Rating

The basic static load rating C0 is used to evaluate loads that may cause permanent deformation at the contact points between the balls and raceways.

Rotational Speed

The permissible rotational speed depends on:

• The 2RSR contact seal design.

• Radial and axial loading.

• Operating temperature.

• Lubrication.

• Mounting fits.

• Heat dissipation conditions.

A catalogue speed value must not be interpreted as the permissible speed under every operating condition.

6200-2RSR-C3 FAG vs Other Bearing Variants

6200-2RSR-C3 vs FAG 6200-2RSR

Both variants have dimensions of 10x30x9 mm and contact seals on both sides.

They differ in radial internal clearance:

• 6200-2RSR - normal internal clearance.

• 6200-2RSR-C3 - greater than normal internal clearance.

These variants must not automatically be considered interchangeable.

6200-2RSR-C3 vs FAG 6200-2Z-C3

The 2RSR version uses contact seals to reduce contamination and help retain grease.

The 2Z version uses metal shields and has different friction and protection characteristics.

6200-2RSR-C3 vs FAG 6200-C-2HRS-C3

Both bearings have nominal dimensions of 10x30x9 mm and increased C3 radial internal clearance.

The 6200-C-2HRS-C3 belongs to the newer FAG Generation C deep groove ball bearing range.

Generation C may differ in:

• Internal geometry.

• Seal construction.

• Load ratings.

• Friction characteristics.

• Operating performance.

Identical dimensions do not guarantee complete technical equivalence.

6200-2RSR-C3 FAG vs SKF 6200-2RSH/C3

Both bearings have dimensions of 10x30x9 mm, contact seals on both sides and C3 radial internal clearance.

Differences may include seal construction, internal geometry, load ratings and lubricant specification.

SKF technical parameters must not automatically be assigned to the FAG bearing.

Selection and Interchangeability of 6200-2RSR-C3 FAG

Before purchasing, verify the following:

1. Complete designation 6200-2RSR-C3.

2. FAG manufacturer identification.

3. Shaft diameter of 10 mm.

4. Housing bore diameter of 30 mm.

5. Bearing width of 9 mm.

6. Contact seals on both sides, designated 2RSR.

7. Increased C3 radial internal clearance.

8. Cage construction.

9. Required load ratings.

10. Rotational speed.

11. Operating temperature.

12. Lubrication conditions.

13. Shaft and housing fits.

14. Radial and axial loading.

15. Environmental conditions.

16. Required bearing service life.

Can 6200-2RSR-C3 Be Replaced with a Standard 6200-2RSR?

Not without checking the operating conditions.

The C3 variant has greater radial internal clearance than the standard version.

If increased clearance is required because of interference fits or operating temperature, using normal clearance may result in unsuitable operating conditions.

Is 6200-C-2HRS-C3 a Replacement for 6200-2RSR-C3?

It may be considered after comparing the complete technical specifications.

Differences between FAG bearing generations must be considered, particularly seal construction and operating characteristics.

Will a 6200 2RS C3 Bearing from Another Manufacturer Fit?

It may have the same nominal dimensions but may not be technically equivalent.

Internal clearance, seals, cage, load ratings, rotational speed and lubrication conditions must be compared.

Applications of 6200-2RSR-C3 FAG

The bearing may be used in appropriately designed rotating mechanisms requiring:

• Support for a 10 mm shaft.

• Contact seals on both sides.

• Increased C3 radial internal clearance.

• Radial load-carrying capability.

• The ability to accommodate appropriate axial loads.

• Reduced contamination of the rolling elements.

Typical application areas for bearings of this type include small electric motors, fans, drive assemblies and compact machine mechanisms.

These are general applications based on bearing construction, not confirmed OEM applications for this specific FAG part number.

Installation and Operating Recommendations

Cleanliness During Installation

Clean the shaft and housing before installation.

Prevent contaminants from reaching the mounting surfaces and seals.

Correct Mounting Fits

Mounting fits must account for loading and operating temperature.

Interference fits may reduce radial internal clearance.

Application of Mounting Force

When mounting the bearing onto a shaft, apply the installation force to the inner ring.

When installing the bearing into a housing, apply the force to the outer ring.

Mounting forces must not be transmitted through the balls.

Seal Protection

Do not damage or remove the 2RSR contact seals during normal installation.

Lubrication

The bearing is factory lubricated.

Grease service life depends on temperature, loading and rotational speed.

Storage

Store the bearing in a clean, dry environment, preferably in its original packaging.

Frequently Asked Questions - 6200-2RSR-C3 FAG

What Are the Dimensions of 6200-2RSR-C3 FAG?

The bearing has a 10 mm bore diameter, a 30 mm outside diameter and a 9 mm width. Its dimensions are 10x30x9 mm.

What Does 2RSR Mean in FAG Bearings?

2RSR indicates contact seals on both sides of the bearing. These seals help retain grease and reduce contamination.

What Does C3 Mean in a FAG Bearing?

C3 indicates radial internal clearance greater than normal.

Are 6200-2RSR-C3 and 6200-2RSR the Same Bearing?

No. They have identical dimensions and seal types but differ in radial internal clearance.

Is 6200-2RSR-C3 FAG Factory Lubricated?

Yes. It is a double-sealed bearing supplied with factory-applied lubricant.

Is FAG 6200 2RS C3 Suitable for an Electric Motor?

It may be suitable if its dimensions, C3 clearance, load ratings, rotational speed and operating conditions meet the motor manufacturer's requirements.

Can 6200-2RSR-C3 Be Replaced with 6200-C-2HRS-C3?

Replacement requires verification of technical parameters. The newer Generation C version may differ in construction and operating characteristics.

Does C3 Mean Higher Load Capacity?

No. C3 identifies increased radial internal clearance, not automatically higher dynamic or static load ratings.

6200-2RSR-C3 FAG - Key Technical Information

6200-2RSR-C3 FAG is a single-row deep groove ball bearing manufactured by FAG, a Schaeffler brand, with dimensions of 10x30x9 mm. It features contact seals on both sides, designated 2RSR, and increased C3 radial internal clearance. The bearing is factory lubricated and designed to support radial and appropriate axial loads. Mounting fits and operating temperature are essential selection factors.
