SKF 6200-2RSH 10x30x9 Deep Groove Ball Bearing

SKF 6200 2RS 10x30x9 mm - Deep Groove Ball Bearing

SKF 6200 2RS is a single-row deep groove ball bearing manufactured by SKF, with dimensions of 10x30x9 mm. It has a 10 mm bore diameter, a 30 mm outside diameter and a 9 mm width. The bearing belongs to the 62 dimensional series and features seals on both sides to protect the rolling elements against contamination and help retain lubricant. The commercial designation 2RS requires confirmation of the exact SKF seal version.

Technical Specifications - SKF 6200 2RS

The commercial designation SKF 6200 2RS does not uniquely identify the manufacturer's exact seal construction. SKF versions such as 6200-2RSH and 6200-2RS1 must be distinguished when selecting the bearing.

The following catalogue parameters relate specifically to SKF 6200-2RSH and should only be used if this exact version is confirmed.

These values must not automatically be assigned to other SKF 6200 2RS variants.

What Does SKF 6200 2RS Mean?

6200 - Bearing Series and Size

The designation 6200 identifies a single-row deep groove ball bearing belonging to the 62 dimensional series.

The designation consists of:

• 6 - deep groove ball bearing.

• 2 - dimensional series 62.

• 00 - bore diameter code corresponding to 10 mm.

The bearing has dimensions of 10x30x9 mm.

Its deep groove construction enables it to accommodate primarily radial loads and appropriate axial loads in both directions.

2RS - Seals on Both Sides

The designation 2RS is commonly used in commercial listings to describe bearings fitted with rubber seals on both sides.

SKF uses more specific suffixes, including:

• 2RSH - contact seals on both sides.

• 2RSL - low-friction seals on both sides.

• 2RS1 - contact seals on both sides, according to the corresponding SKF design.

These suffixes must not be considered technically identical.

The exact sealing arrangement should be identified from the manufacturer's designation on the bearing or its original packaging.

Radial Internal Clearance

The commercial designation 6200 2RS does not independently establish the bearing's radial internal clearance.

A standard SKF 6200-2RSH without an additional clearance suffix has normal radial internal clearance, designated CN.

Versions with increased C3 clearance are identified separately, for example SKF 6200-2RSH/C3.

Internal clearance must be selected according to shaft and housing fits, operating temperature and application requirements.

Alternative Designations and Reference Numbers

The bearing may be searched for using the following commercial variations:

• SKF 6200 2RS

• 6200 2RS SKF

• SKF 6200-2RS

• 6200-2RS SKF

• SKF 6200 2RS 10x30x9

• SKF 6200 sealed bearing

• SKF 6200 double sealed ball bearing

• SKF 6200 10x30x9 mm bearing

Related SKF catalogue designations include:

• SKF 6200-2RSH

• SKF 6200-2RSL

• SKF 6200-2RS1

These are distinct seal designs and should not be treated as confirmed alternative part numbers for the supplied product without verification.

Construction of SKF 6200 2RS

Inner Ring - 10 mm Bore

The inner ring has a bore diameter of 10 mm.

It is designed to operate with a shaft having an appropriately selected mounting fit.

Excessive interference may reduce the bearing's operating internal clearance.

Outer Ring - 30 mm Outside Diameter

The outer ring has an outside diameter of 30 mm.

It is installed in a housing with suitable dimensional tolerances and geometry.

Correct housing support is important for maintaining proper raceway geometry under load.

Bearing Width - 9 mm

The bearing width is 9 mm.

This dimension must be considered when selecting spacers, shaft shoulders and axial locating components.

Balls and Raceways

The bearing contains a single row of balls operating between deep raceways in the inner and outer rings.

The construction enables the bearing to support radial loads and appropriate axial loads in both directions.

Cage

The standard SKF 6200-2RSH version uses a pressed steel cage.

The cage maintains the correct spacing between the balls and reduces direct contact between adjacent rolling elements.

The cage construction should be confirmed when the supplied bearing is identified only by the shortened commercial designation 6200 2RS.

Seals

Seals on both sides help retain lubricant and limit contamination of the rolling elements.

The protection level and friction characteristics depend on the exact SKF seal design.

Load Ratings and Rotational Speed

Basic Dynamic Load Rating C

The basic dynamic load rating is used to calculate the nominal fatigue life of a rolling bearing.

For the catalogue SKF 6200-2RSH version, the basic dynamic load rating is 5.40 kN, equivalent to 5,400 N.

This value does not represent the maximum permissible operating load under all conditions.

Basic Static Load Rating C0

The basic static load rating is used to evaluate loads that may cause permanent deformation at the contact points between the balls and raceways.

For SKF 6200-2RSH, the catalogue value is 2.36 kN, equivalent to 2,360 N.

Fatigue Load Limit Pu

The fatigue load limit for SKF 6200-2RSH is 0.10 kN, equivalent to 100 N.

This parameter is used in bearing life calculations and must not be interpreted as the maximum permissible operating load.

Limiting Speed

The catalogue limiting speed for SKF 6200-2RSH is 17,000 r/min.

The actual permissible rotational speed depends on:

• Radial and axial loading.

• Operating temperature.

• Lubrication.

• Shaft and housing fits.

• Seal friction.

• Heat dissipation conditions.

Speed ratings for one SKF seal version must not automatically be transferred to another.

SKF 6200 2RS vs Other Bearing Variants

SKF 6200-2RSH vs SKF 6200-2RSL

Both bearings have dimensions of 10x30x9 mm.

They differ in seal construction and friction characteristics.

The 2RSL version is designed to reduce seal-related friction.

The 2RSH version uses a different contact seal arrangement.

Interchangeability must be evaluated according to the operating environment and application requirements.

SKF 6200-2RSH vs SKF 6200-2Z

The 2RSH version uses contact seals to limit contamination and retain lubricant.

The 2Z version uses metal shields and has different friction and protection characteristics.

SKF 6200-2RSH vs SKF 6200 Open Bearing

The open SKF 6200 version has no integral seals or shields.

The SKF 6200-2RSH version features contact seals on both sides and factory-applied lubricant.

Both have dimensions of 10x30x9 mm, but they differ in contamination protection and lubrication arrangements.

SKF 6200-2RSH vs SKF 6200-2RSH/C3

Both bearings have identical nominal dimensions and seal designs.

Their radial internal clearance differs:

• SKF 6200-2RSH - normal radial internal clearance, CN.

• SKF 6200-2RSH/C3 - greater than normal radial internal clearance, C3.

The C3 version should be selected according to mounting fits, temperature differences and the required operating clearance.

Selection and Interchangeability of SKF 6200 2RS

Before purchasing, verify the following:

1. Exact SKF catalogue designation.

2. Bore diameter of 10 mm.

3. Outside diameter of 30 mm.

4. Bearing width of 9 mm.

5. Seal type and construction.

6. Required radial internal clearance.

7. Cage design.

8. Dynamic and static load ratings.

9. Permissible rotational speed.

10. Operating temperature.

11. Lubrication conditions.

12. Shaft and housing fits.

13. Radial and axial loads.

14. Environmental conditions.

15. Required bearing service life.

Are SKF 6200 2RS and SKF 6200-2RSH the Same Bearing?

SKF 6200 2RS is a shortened commercial designation.

SKF 6200-2RSH is a specific manufacturer designation.

The exact version must be confirmed before assuming that the two references identify the same product.

Can SKF 6200 2RS Be Replaced with SKF 6200-2Z?

Not without checking the operating conditions.

Both versions have the same nominal dimensions, but their protection systems and friction characteristics differ.

Is a 6200 2RS Bearing from Another Manufacturer Interchangeable?

It may be interchangeable after comparing the complete technical specifications.

Dimensions, seal design, internal clearance, cage, load ratings, rotational speed and lubrication requirements should be checked.

Identical dimensions alone do not guarantee full technical equivalence.

Applications of SKF 6200 2RS

This bearing type may be used in appropriately designed rotating mechanisms requiring:

• Support for a 10 mm shaft.

• Protection of the rolling elements on both sides.

• Radial load-carrying capability.

• The ability to accommodate appropriate axial loads.

• Reduced contamination of the bearing interior.

• Factory-applied lubrication.

Typical application areas for this bearing type include:

• Small electric motors.

• Fans.

• Compact drive assemblies.

• Industrial machine mechanisms.

• Electromechanical equipment.

These are general applications based on bearing construction, not confirmed OEM applications for a particular SKF part number.

Final bearing selection must follow the equipment manufacturer's requirements.

Installation and Operating Recommendations

Cleanliness During Installation

Clean the shaft and housing before installation.

Prevent contaminants from reaching the mounting surfaces and seals.

Correct Mounting Fits

Mounting fits should account for loading, operating temperature and required internal clearance.

Interference fits may reduce radial internal clearance.

Application of Mounting Force

When mounting the bearing onto a shaft, apply the installation force to the inner ring.

When installing the bearing into a housing, apply the force to the outer ring.

Mounting forces must not be transmitted through the balls.

Seal Protection

Do not damage or remove the seals during standard installation.

Damaged seals may allow contaminants to enter or lubricant to escape.

Lubrication

Standard double-sealed SKF deep groove ball bearings of this type are supplied with factory-applied grease.

Grease service life depends on temperature, rotational speed and loading.

Storage

Store the bearing in a clean, dry environment, preferably in its original packaging.

Frequently Asked Questions - SKF 6200 2RS

What Are the Dimensions of SKF 6200 2RS?

The bearing has a 10 mm bore diameter, a 30 mm outside diameter and a 9 mm width. Its dimensions are 10x30x9 mm.

What Does 2RS Mean in an SKF Bearing?

2RS is a commercial designation indicating seals on both sides. SKF uses more specific suffixes, such as 2RSH and 2RS1, to identify particular seal designs.

Does SKF 6200 2RS Have C3 Clearance?

This cannot be established from the shortened designation alone. A C3 version should be identified by the corresponding manufacturer's clearance suffix.

Are SKF 6200-2RSH and SKF 6200-2RSL Identical?

No. They have the same dimensions but differ in seal construction and friction characteristics.

Is SKF 6200 2RS Factory Lubricated?

Yes. Standard double-sealed SKF deep groove ball bearings of this type are supplied with factory-applied lubricant.

What Are the Load Ratings of SKF 6200-2RSH?

The catalogue basic dynamic load rating is 5.40 kN, and the basic static load rating is 2.36 kN. These values refer specifically to SKF 6200-2RSH.

Is SKF 6200 2RS Suitable for an Electric Motor?

It may be suitable if its dimensions, seal design, internal clearance, load ratings and rotational speed meet the motor manufacturer's requirements.

Can SKF 6200 2RS Be Replaced with Another Brand?

A replacement may be considered after comparing the complete technical specifications. Matching dimensions of 10x30x9 mm alone are insufficient.

SKF 6200 2RS - Key Technical Information

SKF 6200 2RS is a commercial designation for a single-row deep groove ball bearing manufactured by SKF, with dimensions of 10x30x9 mm. It belongs to the 62 dimensional series and features seals on both sides to reduce contamination and retain grease. The exact SKF seal version, such as 2RSH or 2RS1, must be confirmed before selecting a replacement.
