SIT-LOCK CAL6F 50/80 SIT Locking Assembly 50x80

Self-Centering Locking Assembly for High Precision Shaft Hub Connections

The SIT-LOCK CAL6F 50/80 SIT is a precision locking assembly designed to create a secure keyless shaft-hub connection without the need for keys, splines or interference fits. Engineered for 50 mm shafts and 80 mm hubs, this self-centering mechanical locking device provides uniform pressure distribution, excellent concentricity and reliable torque transmission. The CAL6F design consists of precision tapered clamping rings that generate a high-friction connection, making it an ideal solution for industrial power transmission systems, machine building and OEM applications requiring fast installation and dependable long-term performance.

Application in Industrial Systems

The SIT-LOCK CAL6F 50/80 is widely used wherever precise shaft-hub connections are required.

Typical applications include:

• Industrial gearboxes
• Electric motors
• Belt pulleys
• Chain sprockets
• Couplings
• Conveyor rollers
• Packaging machinery
• Food processing equipment
• Pumps
• Fans
• Material handling systems
• Industrial automation equipment

Its self-centering design ensures reliable positioning while eliminating backlash in rotating assemblies.

Construction and Design

The CAL6F locking assembly features a compact, self-centering construction developed for medium to high torque transmission.

Key design features include:

• Self-centering locking assembly
• Single taper clamping system
• Internal locking device
• Two precision tapered rings
• High-strength clamping screws
• Uniform radial pressure
• Keyless shaft-hub connection
• Easy installation and removal

The tapered clamping mechanism distributes forces evenly around the shaft, minimizing stress concentrations and improving operational reliability.

Material Properties

Manufactured from high-strength steel, the locking assembly provides excellent mechanical performance.

Material advantages:

• High tensile strength
• Excellent fatigue resistance
• High contact pressure capability
• Dimensional stability
• Wear resistance
• Long service life
• Reliable torque transmission
• Multiple assembly and disassembly capability

The robust construction is suitable for continuous industrial operation under demanding mechanical loads.

Technical Specification

Type: Self-Centering Locking Assembly

Material: High-Strength Steel

Design: CAL6F Single Taper

Inner Diameter: 50 mm

Outer Diameter: 80 mm

Width: 20 mm

Thread: M8

Clamping Screws: 7

Tightening Torque: 35 Nm

Application: Shaft-Hub Connection, Gearboxes, Belt Drives, Chain Drives, Industrial Machinery

Why B2B Customers Choose This Product

Industrial professionals select the SIT-LOCK CAL6F 50/80 because it offers a reliable, maintenance-friendly alternative to keyed shaft connections.

Ideal for:

• OEM replacement
• Maintenance stock
• Industrial service
• Production line support
• Fleet maintenance
• Machine rebuilding
• Power transmission upgrades
• Industrial equipment manufacturing

Its standardized dimensions simplify inventory management and reduce maintenance downtime.

Operational Advantages

• Self-centering construction
• Keyless shaft-hub connection
• High torque transmission
• Excellent concentricity
• Uniform clamping pressure
• Fast installation
• Easy removal
• Reduced shaft and hub wear

Professional Industrial Supply

The SIT-LOCK CAL6F 50/80 is supplied to:

• Maintenance departments
• Industrial workshops
• Agricultural machinery service
• OEM manufacturers
• Machine builders
• Power transmission distributors
• Industrial automation companies
• Equipment refurbishment specialists

It is widely used in preventive maintenance programs and industrial machinery upgrades.
