12306 IJK Miniature Self Aligning Ball Bearing 6x15x5

12306 IJK Miniature Self Aligning Ball Bearing 6x15x5

12306 IJK is a miniature double row self aligning ball bearing designed for compact rotating systems requiring shaft misalignment compensation together with stable high speed operation and reduced installation space.

Self aligning ball bearings differ from standard deep groove ball bearings due to their ability to compensate for minor shaft and housing misalignment during operation. The double row ball arrangement combined with a spherical outer raceway enables:

• compensation of shaft misalignment
• reduction of mounting stresses
• stable operation under shaft deflection
• minimized edge loading on rolling elements

The 12306 IJK model belongs to the category of miniature self aligning bearings used in:

• precision mechanics
• miniature electric motors
• industrial automation systems
• lightweight transmission assemblies
• measuring equipment
• guiding systems
• laboratory devices

The compact dimensions 6x15x5 mm allow installation in miniature mechanical systems requiring low rolling resistance and accurate shaft guidance.

The 12306 IJK bearing is equipped with C3 internal clearance. The C3 designation indicates:

• increased radial internal clearance
• compensation capability for thermal expansion
• improved operating stability at elevated temperature
• better suitability for high speed rotation

C3 clearance is commonly used in miniature applications operating:

• at elevated rotational speed
• under variable temperature conditions
• during continuous operating cycles

The bearing uses a steel cage providing:

• stable ball guidance
• low friction characteristics
• resistance to dynamic loading
• good dimensional stability

The open bearing construction without seals allows:

• operation at high rotational speed
• effective oil lubrication
• minimized rolling resistance

The phrase 12306 IJK 6x15x5 miniature self aligning ball bearing C3 is frequently searched in servicing applications involving precision mechanical systems and compact rotating equipment.

Construction and operating characteristics

The 12306 IJK bearing uses a double row ball bearing construction with a spherical outer raceway allowing self alignment during operation.

Main construction features:

• double row self aligning ball bearing
• miniature bearing design
• spherical outer raceway
• shaft misalignment compensation capability
• C3 radial internal clearance
• steel cage
• open bearing configuration
• low friction torque

The self aligning geometry reduces stress generated by mounting inaccuracies and improves operational durability under minor shaft deflection conditions.

Industrial application context

Miniature self aligning ball bearings are used in applications requiring precise rotational guidance together with compensation for minor shaft alignment errors.

The 12306 IJK model is commonly installed in:

• micro electric motors
• laboratory equipment
• industrial automation systems
• measuring devices
• lightweight transmission systems
• guiding assemblies
• precision mechanisms
• electronic equipment

Miniature self aligning bearings are especially useful in applications where minor shaft misalignment could accelerate wear of standard ball bearings.

Technical specification

Type: Double row self aligning ball bearing

Bearing designation: 12306

Manufacturer: IJK

Bearing type: Miniature self aligning ball bearing

Design: Double row ball bearing with spherical outer raceway

Internal clearance: C3 increased radial clearance

Cage: Steel cage

Sealing: Open bearing without seals

Inner diameter: 6 mm

Outer diameter: 15 mm

Width: 5 mm

Weight: 0,004 kg

Load type: Radial loads and light axial loads

Applications: Precision mechanisms, micro motors, automation systems, laboratory equipment, miniature drive systems

FAQ

What does C3 mean in the 12306 IJK bearing?

C3 indicates increased radial internal clearance allowing more stable operation at elevated temperature and high rotational speed.

How does a self aligning ball bearing differ from a standard ball bearing?

A self aligning bearing compensates for minor shaft misalignment due to its spherical outer raceway geometry.

Is 12306 IJK a miniature bearing?

Yes. The 6x15x5 mm dimensions classify it as a miniature self aligning ball bearing.

Which loads can the 12306 bearing support?

The bearing supports radial loads together with light axial loads.

Where are miniature self aligning bearings commonly used?

They are commonly used in micro mechanics, automation systems, measuring devices and lightweight transmission assemblies.
