SKF 6002-2RSH/C3 15x32x9 Deep Groove Ball Bearing

SKF 6002-2RSH/C3 is a single-row deep groove ball bearing measuring 15x32x9 mm. It has a 15 mm bore diameter, 32 mm outside diameter and 9 mm width. The 2RSH configuration provides contact seals on both sides, while C3 identifies radial internal clearance greater than Normal.

SKF 6002-2RSH/C3 - Product Characteristics

This bearing belongs to SKF's 6000 series of single-row deep groove ball bearings. The exact 6002-2RSH/C3 designation is confirmed by multiple technical distributors as an SKF manufacturer reference.

Verified technical data include:

Manufacturer / Brand: SKF
Designation: 6002-2RSH/C3
Bearing Type: Single-row deep groove ball bearing
Dimensions: 15x32x9 mm
Number of Rows: 1
Bore Type: Cylindrical
Sealing: Both sides
Seal Type: Contact
Radial Internal Clearance: C3
Cage: Sheet metal
Lubricant: Grease
Bearing Material: Bearing steel
Basic Dynamic Load Rating C: 5.85 kN
Basic Static Load Rating C0: 2.85 kN
Fatigue Load Limit Pu: 0.12 kN
Limiting Speed: 14,000 r/min
Mass: approximately 0.03 kg.

Dimensions

The principal dimensions of SKF 6002-2RSH/C3 are:

d - Bore Diameter: 15 mm
D - Outside Diameter: 32 mm
B - Width: 9 mm
Commercial Size: 15x32x9 mm

For this bearing, the dimensional notation 15x32x9 mm corresponds to d x D x B.

Bearing Construction

SKF 6002-2RSH/C3 is a single-row deep groove ball bearing with a cylindrical bore.

The rolling elements are balls operating between deep raceway grooves in the inner and outer rings. This geometry enables the bearing to accommodate primarily radial loads while also supporting axial loads acting in both directions.

The bearing has a non-separable basic construction. Technical data for this exact configuration specify a sheet-metal cage, bearing-steel construction and grease lubrication.

2RSH Contact Seals

The 2RSH suffix identifies the sealing configuration. For this reference, technical data specify contact seals on both sides of the bearing.

The seals help retain grease inside the bearing and restrict the ingress of contaminants into the rolling contact area.

This is technically different from open 6002 bearings and variants equipped with metal shields. Identical 15x32x9 mm dimensions do not make different closure configurations identical.

C3 Radial Internal Clearance

The C3 suffix is an essential part of the SKF 6002-2RSH/C3 designation.

C3 means that the bearing has radial internal clearance greater than Normal.

Therefore, a standard-clearance bearing and this C3 version should not automatically be treated as the same product.

Increased internal clearance may be required when mounting fits, temperature differences between the inner and outer rings or other operating conditions reduce the bearing's effective operating clearance. C3 is not simply a higher-grade version; the correct clearance must match the requirements of the bearing arrangement.

Load Ratings

Technical data for SKF 6002-2RSH/C3 specify:

C - Basic Dynamic Load Rating: 5.85 kN
C0 - Basic Static Load Rating: 2.85 kN
Pu - Fatigue Load Limit: 0.12 kN.

The deep groove raceway geometry allows radial loading together with axial loading in both directions.

The catalogue values C and C0 are standardized ratings used for bearing calculations. They should not be interpreted as simple maximum permissible machine loads. Actual selection requires consideration of load magnitude and direction, required life, speed, fits, operating clearance, lubrication and temperature.

Speed Data

For the sealed 6002-2RSH/C3 configuration, technical sources specify a:

Limiting Speed: 14,000 r/min.

Some technical databases additionally list a reference speed of 50,000 r/min.

These are different technical concepts and should not be treated as interchangeable values. For practical machine selection, the operating speed must be evaluated together with load, lubrication, temperature, sealing and mounting conditions.

Meaning of 6002-2RSH/C3

The complete designation identifies the specific bearing configuration:

6 - deep groove ball bearing family

60 - dimensional series

02 - bore code corresponding to a 15 mm bore

2RSH - contact seals on both sides

C3 - radial internal clearance greater than Normal

The commercial description SKF 6002 2RS C3 is commonly used, but SKF 6002-2RSH/C3 provides more precise technical identification of this product.

SKF 6002-2RSH/C3 vs 6002-2RSH

Both variants have the same principal dimensions:

d = 15 mm
D = 32 mm
B = 9 mm

They also share the 2RSH sealing configuration. The critical difference is internal clearance:

6002-2RSH: Normal internal clearance
6002-2RSH/C3: C3 internal clearance greater than Normal.

Consequently, the C3 suffix should never be omitted when the application specifically requires this clearance group.

SKF 6002-2RSH/C3 vs 6002-2Z/C3

Both bearings can have the same 15x32x9 mm dimensions and C3 internal clearance, but the closure arrangement differs.

6002-2RSH/C3: contact seals on both sides

6002-2Z/C3: metal shields on both sides

The closure arrangement can affect contaminant protection, lubricant retention, friction and speed characteristics. The two versions should therefore not automatically be substituted for one another.

Selection and Interchangeability

When selecting a replacement for SKF 6002-2RSH/C3, compare:

• single-row deep groove ball bearing construction,
• d = 15 mm,
• D = 32 mm,
• B = 9 mm,
• contact seals on both sides,
• C3 radial internal clearance,
• dynamic load rating C,
• static load rating C0,
• speed requirements,
• shaft and housing fits,
• lubrication,
• operating temperature and environment.

A bearing from another manufacturer described simply as 6002 2RS C3 15x32x9 is not automatically confirmed as a complete technical equivalent. The sealing design, clearance specification and other operating parameters should also be compared.

Technical Specification

Manufacturer / Brand: SKF
Designation: 6002-2RSH/C3
Product Type: Deep groove ball bearing
Construction: Single row
Series: 6000
Dimensions: 15x32x9 mm
d - Bore Diameter: 15 mm
D - Outside Diameter: 32 mm
B - Width: 9 mm
Bore Type: Cylindrical
Sealing: Both sides
Seal Type: Contact
Radial Internal Clearance: C3 - greater than Normal
Cage: Sheet metal
Lubrication: Grease
Bearing Material: Bearing steel
Basic Dynamic Load Rating C: 5.85 kN
Basic Static Load Rating C0: 2.85 kN
Fatigue Load Limit Pu: 0.12 kN
Limiting Speed: 14,000 r/min
Mass: approximately 0.03 kg.

FAQ

What are the dimensions of SKF 6002-2RSH/C3?

SKF 6002-2RSH/C3 measures 15x32x9 mm: d = 15 mm bore diameter, D = 32 mm outside diameter and B = 9 mm width.

What type of bearing is SKF 6002-2RSH/C3?

It is a single-row deep groove ball bearing with a cylindrical bore.

What does 2RSH mean?

For this SKF bearing, 2RSH identifies contact seals on both sides.

What does C3 mean?

C3 means radial internal clearance greater than Normal. It is an important selection parameter and should remain part of the complete product designation.

What are the load ratings of SKF 6002-2RSH/C3?

The bearing has a basic dynamic load rating C of 5.85 kN, a basic static load rating C0 of 2.85 kN and a fatigue load limit Pu of 0.12 kN.

What is the limiting speed of SKF 6002-2RSH/C3?

The specified limiting speed is 14,000 r/min.

Is 6002-2RSH/C3 the same as standard 6002-2RSH?

No. The C3 version has radial internal clearance greater than Normal, while the standard 6002-2RSH configuration has Normal internal clearance.

Can another 6002 2RS C3 bearing replace SKF 6002-2RSH/C3?

Not automatically. Dimensions, bearing type, sealing design, C3 clearance, load ratings, speed requirements, fits and operating conditions should be compared before confirming interchangeability.
