SKF 6002-2RS1 15x32x9 Deep Groove Ball Bearing

SKF 6002-2RS1 is a single-row deep groove ball bearing measuring 15x32x9 mm. It has a 15 mm bore diameter, 32 mm outside diameter and 9 mm width. The 2RS1 configuration has seals on both sides, while SKF data for this exact reference specify a cylindrical bore and Normal radial internal clearance.

SKF 6002-2RS1 - Product Characteristics

SKF 6002-2RS1 belongs to the 60 dimensional series of single-row deep groove ball bearings.

The principal verified data are:

Manufacturer / Brand: SKF
Designation: 6002-2RS1
Bearing Type: Deep groove ball bearing
Construction: Single row
Dimensions: 15x32x9 mm
Bore Type: Cylindrical
Radial Internal Clearance: Normal
Basic Dynamic Load Rating C: 5.85 kN
Basic Static Load Rating C0: 2.85 kN
Fatigue Load Limit Pu: 0.12 kN
Mass: approximately 0.03 kg.

The complete 6002-2RS1 designation is important because other SKF 6002 variants have the same principal dimensions but different closure or clearance configurations.

Dimensions

The principal dimensions of SKF 6002-2RS1 are:

d - Bore Diameter: 15 mm
D - Outside Diameter: 32 mm
B - Width: 9 mm
Commercial Size: 15x32x9 mm

For this bearing, 15x32x9 mm corresponds to d x D x B.

SKF data for the exact 6002-2RS1 reference confirm these three principal dimensions.

Bearing Construction

SKF 6002-2RS1 is a single-row deep groove ball bearing.

The balls run between deep raceway grooves in the inner and outer rings. This geometry is primarily suited to radial loading but also enables the bearing to accommodate axial loads acting in both directions.

The bearing has a non-separable basic construction and a cylindrical 15 mm bore.

2RS1 Sealing

The 2RS1 suffix identifies the sealed configuration. The bearing is equipped with seals on both sides.

These seals help retain grease within the bearing and restrict the ingress of contaminants into the rolling contact area.

SKF lists several configurations within the same 6002 dimensional size, including:

6002 - open version
6002-2RS1 - sealed version
6002-2Z - shielded version

These variants can share the same 15x32x9 mm principal dimensions but have different closure arrangements. They should therefore not automatically be treated as technically identical.

Normal Radial Internal Clearance

SKF specifies Normal radial internal clearance for the exact 6002-2RS1 reference.

This is important when comparing the bearing with versions carrying an additional clearance suffix such as C3.

A C3 bearing has greater radial internal clearance than a Normal-clearance bearing. C3 should not be considered an automatic upgrade; the required clearance depends on fits, operating temperature and the conditions of the particular bearing arrangement.

Therefore:

6002-2RS1 ≠ 6002-2RS1/C3

even when their principal dimensions and sealing arrangement are the same.

Load Ratings and Operating Principle

SKF catalogue data for the 6002 size specify:

C - Basic Dynamic Load Rating: 5.85 kN
C0 - Basic Static Load Rating: 2.85 kN
Pu - Fatigue Load Limit: 0.12 kN.

The deep groove raceway geometry allows the bearing to support radial loads and axial loads acting in both directions.

C and C0 are standardized catalogue ratings used in bearing life and static-load calculations. They should not be interpreted as simple maximum permissible operating loads for a machine.

Correct selection also requires consideration of actual load magnitude and direction, rotational speed, required rating life, shaft and housing fits, internal clearance, lubrication, temperature and environmental conditions.

Meaning of 6002-2RS1

The complete designation provides important identification information:

6 - deep groove ball bearing family

60 - dimensional series

02 - bore code corresponding to a 15 mm bore

2RS1 - sealed configuration with seals on both sides

The commercial description SKF 6002 2RS is commonly used, but the complete SKF designation 6002-2RS1 is more precise for a technical product page.

SKF 6002-2RS1 vs 6002

Both versions have the same principal dimensions:

d = 15 mm
D = 32 mm
B = 9 mm

However, their closure configurations differ.

6002 is an open bearing.

6002-2RS1 is sealed on both sides.

The closure configuration should therefore be included when identifying a replacement rather than relying solely on the 6002 basic designation.

SKF 6002-2RS1 vs 6002-2Z

Both variants measure 15x32x9 mm, but their closure systems are different.

6002-2RS1: seals on both sides
6002-2Z: shields on both sides

The difference can affect contaminant protection, lubricant retention, friction and speed capability.

SKF lists these as separate configurations, so identical dimensions do not make them technically identical.

SKF 6002-2RS1 vs W 6002-2RS1

The prefix W is particularly important when comparing these products.

SKF 6002-2RS1 and SKF W 6002-2RS1 both measure 15x32x9 mm, but they are not the same bearing.

The W 6002-2RS1 belongs to SKF's stainless steel bearing range and has different catalogue load ratings. SKF data specify C = 4.88 kN and C0 = 2.8 kN for the stainless steel W version.

Therefore, the W prefix should never be added or removed merely because the principal dimensions match.

Selection and Interchangeability

When selecting a replacement for SKF 6002-2RS1, compare:

• complete bearing designation,
• single-row deep groove construction,
• d = 15 mm,
• D = 32 mm,
• B = 9 mm,
• sealing arrangement,
• radial internal clearance,
• dynamic load rating,
• static load rating,
• required rotational speed,
• shaft and housing fits,
• lubrication and operating conditions.

A 6002 2RS bearing from another manufacturer is not automatically confirmed as a complete technical equivalent solely because it measures 15x32x9 mm.

Technical Specification

Manufacturer / Brand: SKF
Designation: 6002-2RS1
Product Type: Deep groove ball bearing
Construction: Single row
Series: 60
Dimensions: 15x32x9 mm
d - Bore Diameter: 15 mm
D - Outside Diameter: 32 mm
B - Width: 9 mm
Bore Type: Cylindrical
Sealing: Both sides
Radial Internal Clearance: Normal
Basic Dynamic Load Rating C: 5.85 kN
Basic Static Load Rating C0: 2.85 kN
Fatigue Load Limit Pu: 0.12 kN
Mass: approximately 0.03 kg

FAQ

What are the dimensions of SKF 6002-2RS1?

SKF 6002-2RS1 measures 15x32x9 mm: d = 15 mm bore diameter, D = 32 mm outside diameter and B = 9 mm width.

What type of bearing is SKF 6002-2RS1?

It is a single-row deep groove ball bearing.

What does 2RS1 mean?

The 2RS1 suffix identifies the sealed configuration with seals on both sides of the bearing.

What internal clearance does SKF 6002-2RS1 have?

SKF specifies Normal radial internal clearance for the standard 6002-2RS1 reference.

What is the load rating of SKF 6002?

SKF catalogue data specify C = 5.85 kN, C0 = 2.85 kN and Pu = 0.12 kN for the 6002 size.

Can SKF 6002-2RS1 carry axial loads?

Yes. Its deep groove raceway geometry allows it to accommodate axial loads in both directions in addition to radial loads.

Is SKF 6002-2RS1 the same as W 6002-2RS1?

No. The W version is a stainless steel SKF bearing with different catalogue load ratings. The common 15x32x9 mm dimensions do not make the two products identical.

Can another 6002 2RS 15x32x9 bearing replace SKF 6002-2RS1?

Not automatically. Bearing type, sealing, internal clearance, load ratings, speed requirements, fits and operating conditions should be compared before confirming interchangeability.

AI Overview

SKF 6002-2RS1 is a single-row deep groove ball bearing measuring 15x32x9 mm, with seals on both sides and Normal radial internal clearance. Its deep groove geometry supports radial and axial loads in both directions. SKF catalogue data for size 6002 specify C = 5.85 kN, C0 = 2.85 kN and Pu = 0.12 kN.
